International Journal of Power Electronics and Drive System (IJPEDS)

617

Journal homepage: http://iaescore.com/journals/index.php/IJPEDS MATLAB/simulink modelling and simulation of 9-level cascaded H-bridge multilevel inverter with mismatched

Dc Sources

W. V. Yong1, M. S. Chye2, Y. C. Tan3, S. L. Ong4, and J. H. Leong5 1,2,3,5 School of Electrical System Engineering, Universiti Malaysia Perlis, Malaysia 4 School of Microelectronic Engineering, Universiti Malaysia Perlis, Malaysia

Accepted Feb 8, 2019

This paper presents a MATLAB/Simulink model for a 9-level cascaded H- bridge multilevel inverter with mismatched DC voltage sources. The impact of mismatched DC voltage sources on the performance of the 9-level CHBMI is investigated. Due to the mismatched voltages among DC voltage sources, the output fundamental voltage is different from the input reference voltage. To address this problem, a switching-angle calculation technique that accounts for mismatched as well as varying DC voltage sources is demonstrated. The switching angles obtained using this technique is able to produce the desired output fundamental voltage for a wide range of input reference voltages. Since this switching-angle calculation technique does not require complex iterative computation, it has the potential for real-time implementation.

Total Harmonic Distortion

Copyright © 2019 Institute of Advanced Engineering and Science. All rights reserved.

Universiti Malaysia Perlis,

Pauh Putra Campus, 02600, Arau, Perlis, Malaysia. 1.

Introduction

The power quality of the AC output voltage produced by a 9-level cascaded H-bridge inverter (CHBMI) shown in Figure 1 is determined by the harmonic contents of the output voltage waveform which can be measured as total harmonic distortion (THD) . The presence of harmonics in the output voltage waveform is due to the stepped output voltage levels, given by an example of a staircase waveform in Figure 2. Both the output fundamental voltage and the harmonic contents are related to the switching angles applied to the active power semiconductor switches in the H-bridge (HB) modules. Therefore, it is necessary to calculate the switching angles in order to obtain an output voltage waveform with the desired fundamental voltage and the lowest possible THD .

Switching angles are usually calculated off-line and kept in lookup tables for real-time control due to the complex iterative switching-angle calculations involved. The main drawback of this method is that distinct lookup tables are required for each distinct value of output fundamental voltage . Also, large sets of lookup tables result in higher cost associated with the hardware required for real-time calculation.

In practice, battery characteristics such as internal resistance and self-discharge rate are different among units . Consequently, for battery powered H-bridge cells, the voltages among batteries used as DC voltage sources are mismatched. Several researchers developed various strategies to compensate the mismatch among the batteries. However, the compensation circuits require additional components that increase the circuit complexity.

618

In this work, a switching-angle calculation technique based on a geometric approach that accounts for mismatched voltages among DC voltage sources for a 9-level CHBMI is described in Section 2. The impact of mismatched voltages among DC voltage sources on the performance of the system is highlighted in Section 3. Also, the effectiveness of the presented switching-angle calculation technique validated via a 9- level CHBMI MATLAB/Simulink model is demonstrated in Section 3.

Figure 1. A Typical 9-Level Chbmi

Figure 2. Staircase voltage waveform produced by 9-level

Mismatched Dc Voltage Sources

2.

Switching-Angle Calculation Technique

Figure 3 shows the block diagram of the control algorithm, which includes a gain compensation for a 9-level CHBMI. The switching angles are determined from the reference voltage, Vref_pk, as follows:

(1)

where VDC is the nominal voltage of the individual DC voltage sources, ΔVDC is the variation of the individual DC voltage sources, and αn is the n-th switching angle. The relation between the output



MATLAB/simulink modelling and simulation of 9-level cascaded H-bridge … (W. V. Yong)

619

fundamental voltage, V1, and the switching angles can be obtained by analysing the output voltage using Fourier series. The expression of the fundamental voltage can be written as:









The limitation of (1) to produce the switching angles needed to produce the desired output fundamental voltage can be proofed by using (2). The conditions are set as follows: All the DC voltage sources are set to 10 V and the input reference voltage is set to 37.2 V. By using (1), the switching angles obtained for a 9-level CHBMI shown in Figure 1 are: α1=7.73º, α2=23.79º, α3=42.26º and α4=70.30º. Using (2), the output fundamental voltage, V1, obtained from these switching angles is 38.0 V, which is different from the input reference voltage. To obtain the desired output fundamental voltage with minimal error, it is necessary to perform a gain compensation, as shown by the control algorithm given in Figure 3. The expression of the output fundamental voltage with compensation can be obtained by rewriting (2):

(3)

where V1_out is the corrected output fundamental voltage after gain compensation and Δα is compensation of switching angles to produce the desired output fundamental voltage. From the equations above, the corrected output fundamental voltage can be rewritten in terms of input reference voltage and the switching angles as



To produce the desired output fundamental voltage while considering the mismatched voltages among the DC voltage sources, the switching angles are first obtained by using (1) and then, compensation is performed by using (4).

3. Simulation Results

The system has been verified using MATLAB for normalized output fundamental voltage range from 0.00 to 1.00. To verify the impact of mismatched voltages among the DC sources on the performance of the system and the effectiveness of the algorithm to account for mismatched voltages among DC voltage sources, the algorithm is tested for a 9-level CHBMI with mismatched DC voltage sources. The switching angles are first calculated using Equation (1) and (4), assuming that all DC voltage sources are equal and perfectly matched to a 10 V nominal voltage. The switching angles are then used to calculate the output fundamental voltage of 9-level CHBMI with DC voltage sources mismatched to ±20% of the nominal voltage to investigate the impact of the mismatched DC voltage sources onto the performance of the system.

Figure 4 shows the normalized output fundamental voltage versus the normalized input reference voltage for 9-level CHBMI. From the results obtained, without taking into consideration the mismatched DC voltage sources, the output fundamental voltage differs from the desired output fundamental voltage defined by the input reference voltage. After considering the mismatched voltages among the DC voltage sources, the

620

output fundamental voltage is very close to the desired output fundamental voltage given by the input reference voltage. Figure 4. Comparison between normalized output fundamental voltage without and with mismatched DC voltage sources (MDCVS) consideration for 9-level CHBMI Figure 5 shows the switching angles versus normalized output fundamental voltage for a 9-level CHBMI, whilst Figure 6 shows the THD versus normalized output fundamental voltage for a 9-level CHBMI. At the lowest range of output fundamental voltage, the THD increases due to reduced available output voltage levels. Whilst at the highest range of the output fundamental voltage, the THD increases due to the output voltage waveform approaches a square wave.

Figure 5. Switching angle trajectories after gain compensation for 9-level CHBMI with ± 20% voltage mismatch from the nominal voltage of the DC voltage sources Figure 6. THD of output voltage waveform for 9-level CHBMI with ±20% voltage mismatch from the
