Faster Lead-Acid Battery Simulations from Porous-Electrode Theory:

Ii. Asymptotic Analysis

Valentin Sulzera,∗, S. Jon Chapmana,c, Colin P. Pleasea,c, David A. Howeyb,c, Charles W. Monroeb,c

Abstract

Electrochemical and equivalent-circuit modelling are the two most popular approaches to battery simulation, but the former is computationally expensive and the latter provides limited physical insight.

A Theoretical Middle Ground

would be useful to support battery management, on-line diagnostics, and cell design. We analyse a thermodynamically consistent, isothermal porous-electrode model of a discharging lead-acid battery. Asymptotic analysis of this full model produces three reduced-order models, which relate the electrical behaviour to microscopic material properties, but simulate discharge at speeds approaching an equivalent circuit.

A Lumped-Parameter Model, Which Neglects Spatial

property variations, proves accurate for C-rates below 0.1C, while a spatially resolved higher-order solution retains accuracy up to 5C. The problem of parameter estimation is addressed by fitting experimental data with the reduced- order models.

1. Introduction

The popular equivalent-circuit approach to battery mod- elling is efficient, but has limited physical detail and ex- trapolates poorly. Electrochemical models require far more computational power, but include detailed de- scriptions of physical mechanisms, which presumably en- hances predictive capability. Battery management could be improved if there existed easily-solved models with greater mechanistic detail. To that end, this paper puts forward several reduced-order models of lead-acid battery discharge, each derived from a mechanistic description based on an extension of Newman’s porous-electrode theory , which we developed in part I.

Several authors have simplified mechanistic lead-acid- battery models to improve their computational efficiency. Newman and Tiedemann recognise that spatial gradi- ents can be ignored at low current; they state a ‘lumped parameter model’ (LPM) that depends only on time, but do not show how it derives from a porous-electrode model.

Gandhi et al. propose a LPM to underpin an analytical current/voltage relation. Knauff simplifies a porous- electrode model by assuming, without justification, that current is linear in space, and acid molarity, quadratic.

We Deploy Perturbation Methods To Produce A Hi-

erarchy of increasingly complex models. After nondimen-

∗Corresponding Author

sionalization, a diffusional C-rate, Cd–the C-rate scaled with the diffusion time-scale—is found to control how sim- ply the full model can be approximated. Three reduced- order models are derived, validated against the full model, and applied to experiments for parameter estimation.

A leading-order expansion in the diffusional C-rate pro- duces a LPM of the Newman–Tiedemann type, found to be accurate for C-rates below 0.1C. The first-order expan- sion accounts for quasi-static spatial heterogeneity within the electrode sandwich. As well as improving the fit of the full model, this correction has a computationally efficient closed-form expression. Finally, the first-order solution is improved by accounting for diffusion transients. This com- posite model includes just one linear partial differential equation, but matches the full model well up to 5C.

2. Dimensionless Model

In part I, we proposed a general three-dimensional, thermodynamically consistent, isothermal porous-electrode model of a discharging lead-acid battery.

The Detailed

model was simplified slightly on the basis of dimensional analysis to allow solution in a one-dimensional setting. After nondimensionalization, we obtained the following dimensionless system governing the electrolyte concentra- tion c, porosity ε, current density i and potential Φ, elec- trode current density is and potential Φs, and interfacial Preprint submitted to Journal of the Electrochemical Society

1 −ℓp < X < 1. (2.1M)

Equation (2.1e) with the boundary conditions (2.1h) and

(2.1N)

where property values in the negative and positive elec- trode are designated with subscripts n and p, respectively. Typical values of the dimensionless parameters Cd, ιs, βsurf, γdl, ℓ, s, q0, εmax and ε∆are given in Table 1, while concentration-dependent functions D, κ, χ, j0 and U are given in Table A.1. The dimensionless applied current is icell(t) = Icircuit(t)/8Acs, where Icircuit(t) is the applied current in the external circuit and Acs is the electrode cross-sectional area. We define ¯i to be the maximum value of icell(t) with respect to time.

The key parameter is the diffusional C-rate, Cd, which is the C-rate as measured on the diffusion time-scale (or alternatively, the ratio of the applied current scale to the scale of the limiting current).

In the Results section, we will take q0 to be unity (the battery starts from a fully charged state) unless explicitly stated.

Dimensionless Parameters, Relative To The C-

rate, C = Icircuit/Q.

Further Details And Interpretations

can be found in part I.

3. Solutions

We now derive three analytical, approximate solutions to the model system (2.1), and compare these to the nu- merical solution of the full model computed in part I, which we treat as ‘ground truth’.

To Do This, We Note

that the diffusional C-rate, Cd, is small for most practi- cal (low C-rate) applications, and perform an asymptotic analysis near the limit of small Cd.

3.1. Leading-Order Quasi-Static Solution

In this section, we will derive the quasi-static solution in the limit of small Cd, γdl and 1/ιs. Since γdl and 1/ιs are much smaller than one (Table 1), we only take the leading-order terms in their expansions. In contrast, Cd can sometimes be close to one, so we will consider both the leading order and first order in Cd.

(3.1)

in each electrode, and so Φs can be approximated as a function of time only. Applying the boundary condition (2.1h) and defining V (t) = Φs|x=1, we can now replace

Φs,N = 0,

Φs,p = V (t).

(3.2)

We use the integral condition (2.1n) so that we do not need to solve for is to find the voltage, V (t). Hence (2.1f) is only necessary if we want to find is having found j. We also take the leading order in γdl, so that the time derivatives in (2.1g) disappear.

In summary, we simplify the system (2.1) to the follow- ing equations for c(x, t), ε(x, t), j(x, t), Φ(x, t) and V (t):

(3.3G)

and initial conditions (2.1j). As shown in Table 1, the diffusional C-rate, Cd, is equal to 0.6C, where C is the C-rate. Most practical applications have a C-rate below 0.25C, so the diffusional C-rate is usually small. Hence we perform an asymptotic expansion in the limit Cd →0 and assume that we can expand all

(3.4)

where f = c, ε, Φ, j and V . Hence (3.3) becomes to leading

C(0)

.

C(0) = C0,

ε(0) = ε0.

(3.5H)

At first order, equating coefficients of Cd in (3.3) gives

C(1) = Ε(1) = 0

at t = 0.

(3.6L)

Leading-order quasi-static solution. We now seek the so- lution to the lowest order problem.

Integrating (3.5A)

with boundary conditions (3.5f), then integrating again, gives c(0) = c(0)(t). We then integrate (3.5c), use bound- ary conditions (3.5f), and integrate again, to find that

As Defined By (3.5D)

and (3.5e) are functions of time only; the boundary con-

P

= −icell/ℓp.

Sep ≡Εmax

sep ).

Hence To Leading Or-

der, the whole problem is quasi-static. To determine c(0), we need to consider the first-order problem (3.6a) for c(1). Integrating (3.6a) from x = 0 to x = 1 and using (3.7) and the boundary conditions (3.6j) gives a solvability con- dition that determines c(0).

We Can Combine This With

(3.5b), (3.5d) and (3.5e) to obtain a nonlinear differential-

(3.8E)

with initial conditions (3.5h). Integrate (3.8a-c) and re- arrange (3.8d,e) to find the final leading-order solution,

3.2. First-Order Quasi-Static Solution

We now solve the first-order system, (3.6), to find the O(Cd) correction to the voltage. We solve (3.6) as follows: (i) find c(1) using (3.6a), up to an arbitrary constant, k(t); (ii) find k using a solvability condition on c(2), the O(C2

D)

correction to c; (iii) find Φ(1) using (3.6c) up to an arbi- trary constant, An(t); (iv) find An using (3.6d); (v) find V (1) using (3.6e). Firstly, with known c(0) and ε(0), we can integrate (3.6a) with respect to x twice and use (3.6j) to find an explicit equation for c(1) (given in Appendix B).

Having found c(1), we integrate (3.6c), using (3.7) and

(3.10)

where An is an arbitrary constant. We can now integrate (3.6d) from x = 0 to x = ℓn and integrate (3.6e) from x = 1−ℓp to x = 1, using (3.6k) each

1−ℓp

· dx.

3.3. Composite Solution

The quasi-static solution developed in the ‘Leading- order quasi-static solution’ and ‘First-order quasi-static solution’ sections is valid when the current varies slowly, but fails to capture transient behaviour when the current changes more rapidly, such as a jump. To capture such transients, we could rescale time with τ = (t −t∗)/Cd, where t∗is the time of the jump in the current, define C(τ) = c(t) (and likewise for other variables) and expand in powers of Cd. We give the details of such an approach in Appendix C.

Such a transient solution is valid at short times after a jump time t∗, but breaks down at times long after the jump time. To obtain a solution that is valid both at short times after a jump in current and at long times, without having to repeatedly ‘reset’ the transient solution, we use a ‘composite’ solution, which we now develop here.

We consider the lowest order and first order correction for the concentration by taking ˜c = c(0) + Cd c(1). We then

(3.13)

where c(0) and ε(0) are given by the quasi-static problem (3.9) and j(0) is given by (3.7).

4

times, Cd ∂c(1)/∂t is a higher-order term and we retrieve the quasi-static problem (3.6a), while for short times, re- scaling τ = (t −t∗)/Cd, c(0) is constant and we have the transient problem (C.3a) for c(1).

Hence (3.13) Is Valid

uniformly at both short times and long times. The composite solution then consists of solving (3.13)

(3.14)

and finally finding V (1) through (3.10) and (3.11) with c(1) given by (3.14).

4. Results

In the Solutions section,we derived four systems that are approximately equivalent to the full dimensionless sys-

2. Leading-Order Quasi-Static (Loqs) – (3.9)

3. First-order quasi-static (FOQS) – (B.1), (3.10) and

4. Composite – (3.13), (3.10) And (3.11)

The code used to solve the models and generate the results below is available publicly on GitHub . Note that to obtain either the first-order quasi-static solution or the composite solution, we must first solve the leading-order quasi-static problem.

4.1. Reduced-Order Solutions

We now compare results from the four models.

We

treat the full numerical model as ‘ground truth’, and in- vestigate the speed and accuracy of the three other models compared to the numerical model.

The most important output from the model is the volt- age, since this is the variable that we can compare to experimental data (treating current as a known input).

In Figure 1, we compare the voltage during a complete constant-current discharge at a range of C-rates. The dis- charge is deemed to be finished either when the concentra- tion reaches zero anywhere in the cell, or when the voltage reaches a cut-offvoltage of 10.5V.

We observe that all three reduced-order solutions agree well with the numerical solution at very low C-rates (Fig- ure 1a).

As We Increase The C-Rate (Figures1B-D), Only

the first-order solutions (FOQS and composite) agree with the numerical solution; further, a discrepancy appears be- tween the FOQS solution and the numerical solution at early times.

Finally, For Very High C-Rates (Figures 1E-

f) the composite solution still agrees very well with the numerical solution, but the FOQS solution does not, and terminates early, for reasons that we explain below.

To explain the behaviour observed in the voltages, we investigate internal variables, such as the concentration at various states of charge (Figure 2). At a very low C-rate of 0.1C (Figure 2a), the concentration remains almost uni- form throughout the discharge; hence the LOQS solution, which does not take into account any spatial variations, provides a good fit to the numerical solution. At a higher C-rate of 0.5C (Figure 2b), the concentration in the nu- merical solution is no longer spatially homogeneous; this is non-uniformity is captured well by the FOQS and com- posite solutions, but not by the LOQS solution. However, even with the FOQS and composite solutions, there is a discrepancy in the concentration profiles in the positive electrode (Figures 2b,c, right-hand side of the spatial do- main). This is because the solutions from the asymptotic methods assume a uniform interfacial current density, but in the numerical solution the interfacial current density is non-uniform.

Finally, at high C-rates (2C, Figure 2c), there is a dif- fusion transient at the start of the discharge; this is only captured by the composite solution, and not the FOQS solution. This initial diffusion transient also explains the discrepancy between the FOQS and numerical solutions at early times in Figure 1d. In addition to this, we can now see that the FOQS solution terminates early in Figure 1f because the concentration quickly reaches zero.

In Figure 3, we show the relative errors of the voltage obtained from reduced-order models compared to the volt- age obtained from the numerical model. Then, in Table 2, we compare the time taken to solve the various models. We see that the composite solution, leading-order quasi-static and first-order quasi-static solutions are roughly one, two and three orders of magnitude faster than the full numeri- cal solution respectively. Coupled with the errors shown in Figure 3, the speeds shown in Table 2 suggest that in order to solve the model accurately and as quickly as possible, we should use the LOQS model for C-rates below 0.1C, the FOQS model for C-rates of 0.1-1C, and the composite model for C-rates above 1C.

The time taken for the leading-order quasi-static model is independent of grid size, while the time taken for the other models scales linearly with grid size. Note that we can expect to obtain a faster numerical solution by using a different spatial discretisation scheme than Finite Vol- umes, such as Chebyshev orthogonal collocation , and the relative speed-up of the composite solution by using the same discretisation would be similar.

4.2. Voltage Breakdown

As well as obtaining a faster solution to the model, the composite solution allows us to identify the individual overpotentials that contribute to the total drop in voltage from full charge. We write the total dimensional voltage

(F) 5C

Figure 1: Comparing voltages for a constant-current discharge using the parameters from literature (Tables 1 and A.2), for a range of C-rates.

(4.2)

where VU,i, i = n, p are the open-circuit voltages; Vk,i, i = n, p are the kinetic overpotentials, accounting for losses due to the reactions at the electrode-electrolyte interfaces; Vc is the concentration overpotential, accounting for losses due to concentration gradients; and Vo is the Ohmic over- potential in the electrolyte, accounting for losses due to the electric resistance of the electrolyte. Equation 4.2 would usually include a term to account for Ohmic losses in the solid electrodes, but in our reduced-order models this term is zero since ιs is large (c.f. equation 3.1).

, (4.3F)

Together with the quasi-static formulas (3.9a) for c(0) and (B.1) for c(1), equations (4.2) and (4.3a) give an exact formula for the voltage that is valid for most operating C-rates (below 0.5C). For higher C-rates, we must solve (3.13) and use (3.14), instead of (B.1), to find c(1).

In Figure 4, we show the relative contribution from
