Wireless Ev Charging Matlab

Coordination For The Voltage Regulation

Abstract—This paper investigates a decentralized optimization methodology to coordinate Electric Vehicles (EV) charging in order to contribute to the voltage control on a residential electrical distribution feeder. This aims to maintain the voltage level in function of the EV’s power injection using the sensitivity matrix approach. The decentralized optimization is tested with two different methods, respectively global and local, when EV take into account their impact on all the nodes of the network or only on a local neighborhood of their connection point. EV can also update their decisions asynchronously or synchronously.

While only the global approach with asynchronous update is theoretically proven to converge, using results from game theory, simulations show the potential of other algorithms for which fewer iterations or fewer informations are necessary. Finally, us- ing Monte Carlo simulations over a wide range of EV localization configurations, the first analysis have also shown a promising performance in comparison with uncoordinated charging or with a ”voltage droop charging control” recently proposed in the literature.

Index Terms—Voltage control - Decentralized algorithms - EV

V

OLTAGE regulation is one of the significant ancillary services in distribution systems. In the evolution towards a ”smarter grid”, it has to become more flexible to deal with the variation of consumer’s need and distributed generations .

In this context, smart grid is envisioned to make the most of potential interactions between power systems and electric vehicles (EV). A large part of literature has been devoted to a centralized approach (see ) to perfectly schedule EV charging according to various objectives (power losses, voltage deviations, charging costs...) while the behavior of end users is less considered. Thus, a decentralized approach could contribute to the further development of practical coordination mechanisms, the next step before real implementation.

recently gave an overview of smart mechanisms explored in EV smart charging literature comparing centralized and decentralized results. Some of the distributed methods leading to promising results are based on game theory, which is a powerful tool to study their properties . This comes from the fact that Nash equilibria may be attractors for many distributed mechanisms designed in coordination problems. Consequently, these equilibria, and particularly the study of their efficiency, nault SAS, in Paris, France, Y. He PhD student at Supelec Power System De- partment, M. Hennebel researcher and professor at Supelec Power System De-

Manuscript Received June 19, 2013

may play a major role in this context. Recent literature in this field contains which optimizes the interaction between a transformer and a group of EVs and in the context of wind power integration. To the best of our knowledge, our work is the first to apply this framework to the issue of voltage control.

A. Ev Charging Modeling

The availability of EV charging is concerned with a wild research on user’s behavior. In this work, it will be considered that most of users park their car at home during the night hours and require that it is enough charged to travel next day.

The EV charging in this context can be simply modeled as a controllable power-constant load in the band of [0, Pmax], where Pmax is the maximal charging power of EV. The value of Pmax is varied from 3kW to 48kW, depending on different technologies of EV charging. With the state-of-charge (SoC) representing the charging state of EV batteries, the constraints

(1)

where SoCinit is the initial value when EV parks at home, SoCmin is the minimal acceptable value for the user’s next day traveling, SoCmax the maximal value limited by the battery of EV and Pt the EV charging power during time slot t.

Given the SoC at time t, and SoCmin (respectively SoCmax), the minimal (respectively maximal) charging power at time t, denoted by P t (respectively P t), can be calculated, providing P t ≤Pt ≤P t .

(2)

As known, cables on distribution systems have a great R/X ratio (close to 1). Hence the active power delivery to EV chargers can generate voltage drops, and a charging power modulation can contribute to the voltage control, as is highlighted hereafter. In the following, time indexes will be omitted given that the proposed methodology is repeated at each time slot.

B. Voltage Control With A Sensitivity Analysis

The sensitivity analysis is used to evaluate the changes of some quantity η of interest if changes of some parameter p take place in electric systems. In this work, the changes of bus voltage magnitude ∆V will be evaluated and the parameters of concern are bus power injections P, Q.

2

The concerned sensitivity matrix comes from the network’s

(3)

where Pi, Qi, Vi and δi are respectively the active and reactive power injection, bus voltage magnitude and angle at bus i; Yij and θij are respectively the module and argument of the element (i, j) of the network admittance matrix.

By calculating the partial derivatives of (3), its Jacobian

(4)

The coupling of V -P and V -Q can be expressed from the

(5)

where p is the notation of the set of pilot nodes whose voltage profile should be maintained, while c is the notation of the set of nodes where load injection is controlled. The matrices SV p,P c and SV p,Qc are called sensitivity matrices respectively for the coupling V -P and V -Q.

Considering active power control is concerned in EV charg- ing, only the matrix SV p,P c will be used for this study. The charger converter could also allow a reactive power control.

Before presenting the decentralized algorithms to control

V

V

Fig. 1.

Objective Concerning Voltage Regulation

This will permit to quantify how efficient is the voltage regulation. In practice, this must be determined according to the penalties paid by the Distribution Network Operator (DNO) to keep the voltage within its standard limits. With this definition, while the voltage is between its standard limits (0.9 and 1.1 pu), the DNO has no penalty, and these penalties are quadratic out of this interval. As a comparison and as presented in dashed in Fig.1, a second metric will be considered here, called ”crenel” function: 0 between 0.9 and 1.1 pu, 1 otherwise. This is a first step to analyze the sensibility of the results to the metric used.

C. Decentralized Algorithm For Voltage Control

The decentralized algorithm used in this work is an iterative algorithm which is called the best response dynamics (BRD) in game theory . This implements a communication phase taking place off-line, before charging begins, to coordinate charging decisions of all the EV connected to the same network. Note that an online application of the proposed methodology could also be considered : if the charging at time t has already begun but if there is a need for updating the charging decisions (for example, a new EV has just connected to the network) before time t + 1, the decentralized process could be applied again, having updated the charging needs of all the EV which were charging at this time. As soon as a new charging configuration is obtained, then it is applied.

By default, without knowing the state of the voltage on the pilot nodes, each EV (with an automaton) initially chooses a charging power (for example Prated). Receiving all the EV charging decisions, an aggregator calculates the voltage on all the pilot nodes and feedbacks EV with this information.

Therefore each EV updates its charging decision to minimize an objective and reports this change to the aggregator. This procedure is then repeated while a stopping criterion is not reached.

Observe that EV can update their decisions synchronously or asynchronously (EV 1 updates its choice, then the aggregator calculates and send the pilot nodes’ voltage to all the EV, then EV 2 updates and reports its charging power...). Once this communication phase is finished, each EV knows its charging power.

Using the sensitivity matrix, two decentralized approaches for the voltage regulation will be distinguished according to the objective used by EV to update their charging decisions.

In the first one, all EV follow the same objective which concerns all pilot nodes. Setting ∆Pi and supposing ∆P−i = (∆P1, ∆P2, ..., ∆Pi−1, ∆Pi+1..., ∆PI) fixed, EV i minimizes

(7)

where Vp is the actual voltage measurement and Vref the setpoint for voltage control. In the second one, EV i is more particularly concerned with the voltage on its neighborhood, denoted by Vi, and defined by the electrical network topology (typically, a single feeder or a part of this feeder) given that its charging choice can more directly influence the state of these nodes. To update its

(8)

It should be noted that one key advantage of the local approach in comparison to the global one is that only the local
