I2C Protocol Implementation on FPGA | Final Year VLSI / FPGA Projects

I2C Protocol Implementation on FPGA — Project Hub 2026

I2C protocol implementation on FPGA with Verilog master/slave, device demos, verification and IP packaging.

Typical stack: Verilog/SystemVerilog, Vivado or Quartus, ModelSim/Questa, FPGA boards (Basys3, Nexys A7, DE10-Lite), synthesis timing/area/power reports.

Tools & Hardware

Verilog / SVVivadoQuartus ModelSimBasys3 / NexysDE10-Lite

Best Related Project Topics

43+ topics with simulation tools and hardware used.

#	Project Topic	Tools / Hardware
I2C Master · Core
01	I2CI2C Master Controller in Verilog (Standard Mode)	Verilog · ModelSim · FPGA
02	I2CI2C Master with START/STOP/RESTART Generation	FSM · Verilog
03	I2CParameterized I2C Clock (SCL) Generator	clock stretch notes · Verilog
04	I2CI2C Master Byte Write / Byte Read Sequences	transaction FSM
05	I2CI2C Master with Multi-Byte Burst Transfer	burst · FIFO
06	I2CClock Stretching Handling in Master RTL	stretch detect · Verilog
07	I2C7-bit Addressing Master with ACK/NACK Check	protocol · TB
08	I2CRepeated START for Combined Write-Then-Read	EEPROM style access
I2C Slave · Multi-Device
09	SlaveI2C Slave with Register File	Verilog · slave FSM
10	SlaveAddress Decode for Multiple Soft Slaves	addr map · FPGA
11	SlaveSlave Clock Stretching Example	stretch · Verilog
12	SlaveI2C Slave Interrupt / Flag on Data Ready	status flags
13	SlaveMaster–Slave Loopback Test on One FPGA	internal bus
Protocol Details · Edges
14	ProtOpen-Drain / Pull-up Modelling in Simulation	TB pull-up model
15	ProtGlitch Filtering on SDA/SCL Inputs	digital filter · Verilog
16	ProtArbitration Notes for Multi-Master (Concepts)	protocol theory
17	Prot10-bit Addressing Extension Outline	protocol notes
18	ProtFast-Mode Timing Parameter Checklist	timing table
Verification
19	TBI2C Protocol Assertions (START/STOP/ACK)	SVA · ModelSim
20	TBRandomized Master Transaction Testbench	SystemVerilog
21	TBSlave Behavioral Model for Master Testing	BFM · TB
22	TBError Injection: Missing ACK, Bus Stuck	fault TB
23	TBCoverage of Read/Write/Restart Paths	coverage plan
FPGA · Real Devices
24	DevI2C EEPROM Read/Write Demo on Basys3	EEPROM · PMOD · Vivado
25	DevI2C Temperature Sensor Streaming	sensor · UART out
26	DevI2C OLED Display Text Driver	OLED · I2C · FPGA
27	DevI2C RTC Time Read and Display	RTC · 7-seg
28	DevMulti-Sensor I2C Bus Scan Utility	addr scan FSM
System · Bridges
29	SysUART-to-I2C Bridge Command Interface	UART · I2C master
30	SysSPI-to-I2C Protocol Bridge Concepts	bridge FSM
31	SysSoft CPU MMIO Driver for I2C Master IP	bus wrapper
32	SysWishbone/AXI-Lite Style I2C IP Wrapper	bus IP
33	SysBoot Config from I2C EEPROM Concept	config notes
Coding · IP
34	IPReusable I2C Master IP with Clear Generics	IP packaging
35	IPXDC Constraints for Open-Drain I2C Pins	XDC · IOSTANDARD
36	IPCompare Bit-Bang I2C vs FSM Master	resource · robustness
37	IPLint and CDC Checklist for I2C RTL	lint · CDC
38	IPDocumentation: Timing Diagrams for All Phases	docs
Capstone · Docs
39	CapFull I2C Master+Slave Package + Device Demo	complete
40	CapLab Sequence: From Bit-Bang to Full Master	labs
41	CapPoster: I2C Frame Format & State Machine	PPT
42	CapViva: ACK, Stretching, Open-Drain, Arbitration	Q&A
43	CapThroughput Measurement Master ↔ Sensor on Board	measurements
🔧 Extended Topics · Tools & Hardware
44	ExtI2C Bus Clear Sequence on Stuck SDA	recovery FSM
45	ExtSMBus Timeout and PEC Concepts in RTL	SMBus notes
46	ExtI2C Hot-Swap / Live Insertion Awareness	guidelines
47	ExtMulti-Master Arbitration Simulation Model	TB arbitration
48	ExtI2C EEPROM Page Write with ACK Polling	EEPROM FSM
49	ExtSoft I2C Bit-Bang vs FSM Master Resource Compare	utilization
50	ExtI2C + UART Dual Debug Console Mux	mux · dual
51	ExtCapacitive Load vs Pull-up Strength Notes	hardware notes
52	ExtI2C Address Conflict Detector Utility	scan · flags
53	ExtPMOD Sensor Suite Lab: Temp + Accel + EEPROM	multi device
54	ExtFormal Property: Every START has STOP Eventually	SVA liveness
55	ExtCapstone: Configurable I2C Master IP with Driver API	IP + API docs
