It's worth noting that this tutorial specifically covers Bluetooth Low Energy (BLE, Bluetooth 4.0). If you are looking for information on Classic Bluetooth (Bluetooth 2.0), please refer to a similar tutorial Arduino - Bluetooth .

The HM-10 is a Serial BLE module that functions as a Serial to Bluetooth Low Energy converter. It performs the following actions:

Specifically, when using an Arduino to communicate with a smartphone app (Android/iOS), the following occurs:

The Bluetooth Serial Monitor App is a mobile application that mimics the appearance of the Serial Monitor in Arduino IDE. It allows communication with an Arduino board through Bluetooth without the need for additional code in the Arduino sketch. To use it, follow these steps:

With these steps completed, you can now send and receive data from the Arduino as if you were using the Serial Monitor in Arduino IDE, without the need to modify your existing Arduino code or add any Bluetooth-specific code.

The Arduino code can use other pins by replacing the Serial object with an alternative such as Serial1, Serial2, or SoftwareSerial (if available).

To transmit data from an Arduino board to a Bluetooth app on a smartphone, the following Arduino code can be used. This example demonstrates sending the message âArduino here, command me!â from the Arduino to the smartphone app every second

To use the code and connect an Arduino board to a smartphone via BLE, follow these steps:

If you follow the steps and run the code, you will observe that the data displayed on the Serial Monitor of the Arduino IDE and on the Android app will match.

When you complete the steps above, you will notice that the information displayed on the Serial Monitor of the Arduino IDE and the Android app will be the same

The following Arduino example code utilizes commands âONâ and âOFFâ received through the Bluetooth Serial Monitor App to turn on/off a built-in LED.

You can see the instructions in more detail in Arduino controls LED via Bluetooth/BLE tutorial

The following Arduino code receives an angle value from the Bluetooth Serial Monitor App to control the angle of a servo motor.

You can see the instructions in more detail in Arduino controls Servo Motor via Bluetooth/BLE tutorial

If the Bluetooth Serial Monitor app is useful for you, please give it a 5-star rating on Play Store . Thank you!

Disclosure: Some of the links in this post are affiliate links. This means that, at zero cost to you, Learn Robotics will earn an affiliate commission if you click through the link and finalize a purchase. Learn Robotics is a participant in the Amazon Services LLC Associates Program, an affiliate advertising program designed to provide a way for websites to earn advertising revenues by advertising and linking to Amazon.com.

I am back again with a simple electronics tutorial for beginners. In this post, I will show you how to get started with the Bluetooth Low Energy (BLE) 4.0 module to control LEDs. This project can be adapted to also control relays or robots . BLE is not like normal HC05/06 modules , because it works on Bluetooth V4.0. To be able to connect to this module, your smartphone must have bluetooth version 4 or higher.

First, connect the bluetooth module on the breadboard. The bluetooth module RXD pin requires 3.3V, while the Arduino supplies a 5V output. Therefore, we will create a voltage divider using 1K and 2K Ohm resistors to adjust this voltage.

When you’re finished, make the following connections (Bluetooth Module -> Arduino):

Be sure to connect the resistors to the bluetooth module as shown in the picture. Then, connect one end of resistor (2 KΩ) to GND and other resistor (1 KΩ) to TX pin of the Arduino. The BLE modules have a different pinouts, so make sure you read the labels carefully before connecting.

Now, connect two LEDs on breadboard in series with 1 KΩ resistors. Then attach the LEDs to pins 8 and 9 on the Arduino. Here’s what it should look like when you’re done.

Now, let’s write a code to control LED’s using Smartphone over Bluetooth. We will achieve this using Serial communication. First, initialize the variables and pins as shown bellow:

Then write the setup() method to set the pins as Outputs and enable Serial communication.

Finally, we need to write the loop() method to execute the main logic for control.

With that done, we can now upload the code to the Arduino board. Make sure you disconnect the bluetooth module before uploading the code. (The TX/RX pins are used by Serial Communication when uploading sketches.)

To connect your phone to Bluetooth first you need a Bluetooth Serial App. I’ve used Bluetooth Serial Terminal .

After the connection is established, press the ‘M1’ key to assign it a value. Assign ‘M1’ = 1 and ‘M2’ = 2.

Now power up the Arduino and Click M1 on the Smartphone App. You should see the first LED turn on. Click M1 again to turn the LED off. Repeat this process with M2 for the second LED.

And that’s it! Now that you know how to control LEDs with Arduino through Bluetooth, you can tinker around with this tutorial and modify the code to control your own projects.

If you have any questions or face any difficulty, feel free to ask in the comments below. In next tutorial, I will show you how to make bluetooth controlled robot.
