A digital dice roller, controlled by Arduino. Each dice is represented by 7 LEDs that are arranged according to standard dice pip pattern .

There are two dice and one button. Pressing the button rolls the dice, displays a sequence of random numbers, followed by the result.

In this tutorial, weâre going to make our very own Arduino dice circuit. This is a simple project and is great for introducing yourself to more of the basics of the Arduino.

Much like the Arduino traffic lights project this project uses a variety of LEDS and resistors to make up the circuit. We will also be using a physical switch to tell the Arduino when to generate a new dice face.

You can go further with this project by making a special case for the circuit and LEDs. Excellent if you want some electronic dice to play your next board game with.

If you want to see how to do this project visually then be sure to check out the video below. We go through all the steps you need to know to get this up and running.

I have gone and prepared a video that will take you through all the steps to set up this dice circuit and bring it to life using the Arduino.

If you prefer a detailed written tutorial, then you can find it right underneath the video.

The dice circuit is a relatively easy one and can be quickly assembled. There are ways to improve the circuit, but for this tutorial, we will keep it basic.

I have made a circuit diagram below to help you be able to place everything in the right place. I will explain more about the circuit straight underneath the diagram.

A switch is set up in a H like circuit, for example in our diagram it is a sideways H. Upper left and upper right leads are separate from the bottom leads. When you press the button it connects the upper and bottom leads forming a circuit thus activating our dice.

We run a 3v3 connection to the switch and have a 100k resistor to ground. In between the 100k resistor and the switch we have the wire running to pin 2. This will detect whenever the switch has been pressed.

All of LEDS are positioned to resemble a die face. I have spaced these out a bit more so itâs easier to see on the diagram circuit above. You can place yours much closer together if you would like it to look much more like a proper die .

Each of LEDS are connected to the ground rail via a 100-ohm resistor. The positive end of the LEDS are then connected to a pin on the Arduino. You can see which LEDS are connected to which pin in the table below.

The code in this project is again very similar to the traffic light project. However in this one we introduce a input device (switch) and also produce a random number using the “ randomSeed() ” function.

This code is pretty long so I recommended downloading it from here or from our GitHub . I will take a few snippets from the code explain exactly what weâre doing to help you better understand the code.

In the example below, I am declaring the variables. “ BottomLeft ” refers to the location of the LED this makes it easier to identify when editing the script. The number weâre giving these variables are the pins that the LEDs are connected to.

The “ state ” and “ randNumber ” variables will be used for the storing of numbers. You will see this in action in a bit.

This next code snippet is the setup and is where we assign pins to be either output or inputs and anything else we need to set up before we execute any further code. We use RandomSeed for setting up a random number generator.

The loop part of our script continues to loop through until the Arduino is either turned off or a new set of code is uploaded. At the start of Arduino dice loop we check to see if the switch has been pressed (high).

If the conditions are met, then we change the state to 1 and get a random number between 1 and 7. Once we have the random number we check to see what it is and run the relevant function.

Once the function is done we wait for 4 seconds and then turn the LEDS off and return to our normal state of 0.

Below is an example of the six function. This function is called whenever the dice produces the number six. As you can clearly see, it turns all the relevant LEDS to high.

This will make all the required LEDS that form six, turn on so you get the correct dice face displaying on the circuit.

Again, this page doesn’t have the entire code so don’t forget to download it so you can put it on your Arduino. You can download it from here , or find it on our GitHub .

I hope that you enjoy this Arduino dice project and that it has helped teach you more about the basics of the Arduino and coding. If you want to leave feedback, have questions or anything else be sure to leave us a comment below.

If pressed, it simulates a roll of the dice, then updates the LEDs with the new value.

Can you please do the code over again for the Arduino dice project its says “five was not declared in this scope.” it also say that for 1,2,3,4,5,6. Can you please help?

As mentioned in the tutorial, we stored the full code over at GitHub or as a download .

The "Dice Roll with Arduino" project is an interactive simulation of a dice roll using an Arduino, a pushbutton, and a 7-segment display. When the pushbutton is pressed, a loading animation is displayed on the 7-segment display, followed by a random number between 1 and 6 — simulating the roll of a dice. This project is perfect for beginners who want to improve their understanding of Arduino basics while creating fun, interactive electronic projects.

Loading Animation: A "loading circle" effect is displayed on the 7-segment display by lighting up each segment in sequence, giving the illusion of rotation.

Random Dice Roll: After the loading animation, a random number between 1 and 6 is generated and displayed on the 7-segment display to simulate a dice roll.

7-Segment Common Cathode Display: Displays the loading animation and the dice roll result.

Tinkercad: Used to create the circuit diagram and simulate the project before building it physically.

ChatGPT: Provided assistance throughout the project by offering code suggestions, troubleshooting tips, and explanations for complex parts of the project, helping streamline development and resolve any issues quickly.

Setup and Initialization: Configures the pins connected to the 7-segment display and the pushbutton. It also initializes the random number generator.

Loading Circle Animation: Uses a sequence of digital writes to create a circular animation on the 7-segment display.

Random Dice Roll: When the button is pressed, the loading circle animation is displayed, followed by a random number between 1 and 6, which is generated and shown on the 7-segment display.

Display Functions: Individual functions for each number (1 to 6) display the corresponding segments on the 7-segment display.

Dice Roll with Arduino – Designed a digital dice roller using Arduino, a pushbutton, and a 7-segment display. Pressing the button triggers a "loading circle," followed by a random number display (1–6) to mimic a dice roll. This project highlights skills in microcontroller programming and electronics, creating an interactive, functional display.

Build a digital dice using an Arduino Uno and an LCD screen; upload the code to Arduino Uno , test the button to ensure it generates random numbers (1–6).

This circuit works like real dice but uses electronics , as this is a simple and easy and a fun project for beginners.

The LCD shows nothing or the last number, but when we press the button, 5V goes to pin 2 and the Arduino reads a HIGH signal and generates a random number from 1 to 6.

Then the LCD displays that number as the dice result, and when the button releases, the system waits for the next press.

To build a Digital Dice Circuit using Arduino Uno follow the below steps for connection:

To conclude, this Digital Dice Circuit using Arduino Uno is easy to make, as it works like electronic dice.

We can also learn how button works and we can see how LCD shows number; here Arduino makes random number, furthermore, its good for beginners which helps to practice coding and circuit.
