In this project, we will make Hand Gesture Recognition System using PAJ7620 Sensor & Arduino Board. This PAJ7620 gesture sensor can recognize nine gestures, including moving Up, Down, Left, Right, Forward, Backward, Clockwise, anti-clockwise, and wave. We can use the gesture recognition system in medical applications or control lights, robots, HMI, games, using IR LED and optical CMOS array.

Gesture Recognition is a technology that uses sensors to read and interpret hand movements as commands. Gestures originate from any bodily motion or state but commonly originate from the face or hand. A gesture is an action that has to be seen by someone else and has to convey some piece of information. Gesture Recognition can be considered a way for a computer to understand human body language.

Earlier we learned about APDS9960 Gesture Recognition & RGB Color Sensor. You can check the article to get started with Gesture Sensors.

This product is based on the PAJ7620U2 gesture recognition sensor, which recognizes gestures in 9 different directions, including up, down, left, right, front, back, clockwise, counterclockwise, and rocking.

The gesture recognition module uses the I2C interface and can be programmed and controlled by using the corresponding PAJ7620 Arduino library function. The signal returned by the gesture recognition module can be used as a control signal by the robot, thereby realizing the control of the robot.

The built-in recognition algorithm is quite intelligent, freeing both hands from blunt keys. Gesture recognition sensors can be used for non-contact control scenarios such as contactless mice, smart homes, car click device controls, robot interactions, and more.

PAJ7620U2 also offers built-in proximity detection for the purpose of sensing objects approaching or departing. The PAJ7620U2 is designed with great flexibility in a power-saving mechanism. The PAJ7620U2 is designed to operate from 2.8V to 3.3V over -40°C to +85°C and the pull-up voltage for the I2C bus and interrupt line is from 1.8V to 3.3V.

Let us interface the PAJ7620 Gesture Recognition Sensor with Arduino using the simple I2C interface.

The connection is fairly simple. Connect the VCC, GND, SDA & SCL pin of PAJ7620 to Arduino 3.3V, GND, A4 & A5 respectively.

In my case, I am using an Arduino Nano board. You can use any other Arduino-compatible microcontroller board.

There are multiple libraries for interfacing the PAJ7620 Sensor with Arduino. One of the libraries is written by Seeed Studio. Download the library from the following link.

The following code is taken from the library example. Copy the following code and paste it to the Arduino IDE. Then upload the code.

After uploading the code, open the Serial Monitor. Then swipe your hand in different directions and make different gestures. The gesture indication will be shown in the Serial Monitor. The tests are straightforward, just plug in and start moving your hands.

You can modify the detection speed for all and for the forward and backward alone. Also, keep the module on a flat surface, otherwise, the clockwise and anti-clockwise gestures won’t be detected.

In this part, I’ll use an LCD i²c screen to show the gesture detected. Using this method you can adapt it to whatever project you’re working on.

Connect the I2C LCD Display to the I2C Pin and power the LCD Display with 5V Pin of Arduino.

Now you can swipe the hand in a different direction to show the Gesture movement on the LCD screen.

Similarly, move your hand in forward and backward directions for a forward-backward gesture.

Finally move your hand in an upward and downward direction for an up-down gesture.

You can rotate your hand in clockwise or counterclockwise for rotational movement detection.

Apart from the basic 9 Gesture Moment, you can add right-left, left-right, up-down, down-up, forward-backward, and backward-forward for other gesture detection.

In this tutorial you will learn how to use the PAJ7620U2 Gesture Sensor with Arduino or other common microcontrollers such as the ESP32 or ESP8266.

We will be using three different Arduino libraries to recognize gestures with the PAJ7620U2 sensor. And we will use the gesture detection of the PAJ7620U2 to control the position of a servo.

For other gesture sensors have a look at our tutorials for the APDS-9930 and the APDS-9960 Gesture Sensor.

For this project you will need an PAJ7620U2 sensor and a microcontroller. I used an Arduino Uno but any other Arduino or any ESP32/ESP8266 will work as well, as long as it provides a 3.3V power output. One of the examples also uses a servo, but this is not an essential part for this project.

Makerguides is a participant in affiliate advertising programs designed to provide a means for sites to earn advertising fees by linking to Amazon, AliExpress, Elecrow, and other sites. As an Affiliate we may earn from qualifying purchases.

The PAJ7620U2 is a very small (5.2x3x1.88 mm) gesture detection sensor. It can recognize 13 human hand gesticulations such as moving up, down, left, right, forward, backward, circle-clockwise, circle-counter, clockwise, waving and combinations of the some of the gestures, e.g. up-down.

Note that there is also a PAJ7620 sensor that is very similar to the PAJ7620U2 but recognizes only 9 gestures.

The PAJ7620U2 has two detection modes: fast and slow. Gesture speed is 60°/s to 600°/s in slow (normal) and 60°/s to 1200°/s in fast (gaming) mode.

The chip is designed to operate from 2.8V to 3.6V, with a current consumption of just 2.82 mA, and it communicates via an I2C interface with up to 400 kbit/s.

For more detailed information have a look at the datasheet for the PAJ7620U2 linked below:

The PAJ7620U2 chip is too small to connect it to an Arduino directly. Typically, you will need a breakout board as shown below:

In the next section I show you how to connect a PAJ7620U2 breakout board to an Arduino.

Thanks to the I2C interface of the PAJ7620U2, connecting it to an Arduino is easy. First, connect the SCL pin of the PAJ7620U2 breakout board to A5 of the Arduino. Similarly, connect SDA to A4 of the Arduino. Next, connect GND to GND and 3.3V to VCC of the PAJ7620U2.

Make sure that you use 3.3V as power supply. The PAJ7620U2 sensor is not rated for 5V and breakout boards for the PAJ7620U2 typically do not have a voltage regulator.

Before we can write any code to detect gestures with the PAJ7620U2 we need to install a library. I went with the PAJ7620U2 Library by Seeed-Studio. To install this library, open the Library Manager , search for “PAJ7620”, find the library “Gesture PAJ7620” by Seeed-Studio and click on INSTALL

With the library installed, let’s write some test code to try the sensor out. Upload the following code, open the Serial Monitor and wave your hand in front of the sensor in a distance of about 5cm.

You should see the following output on your Serial Monitor after passing your hand across the sensor in all four directions:

The picture below shows the orientation of the sensor and the directions you have to move your hand across the sensor to get the corresponding gesture readings:

As of Oct 2024 the PAJ7620U2 Library by Seeed-Studio that can be installed via the Library Manager is limited to version 1.0.0. While Seeed-Studio has released an updated version 2.0.0, it can’t be installed via the Library Manager. In this section I show you how to install and use the updated library.

Before installing version 2.0.0 make sure that you uninstall version 1.0.0 first! You can do this by opening the Library Manager, search for ” PAJ7620″, and press “UNINSTALL” for the PAJ7620U2 Library by Seeed-Studio.

Then go to the Grove_Gesture repo , click the green “Code” button and then press “Download ZIP”, which downloads a file named “Grove_Gesture-master.zip” to your computer.

You can then install this ZIP library via Sketch -> Include Library -> Add .ZIP Library ...

Below you will find a simple example that uses the updated PAJ7620U2 Library to recognize four gestures (Up, Down, Left, Right):

It is essentially the same example as the one shown for old, version 1.0.0 library. But you can see that the new code is a bit more elegant, since there is now a Gesture and a result object.

The Grove_Gesture repo has other examples that demonstrate how to recognize 9 gestures or 15 gestures . However, if you look at the code, it is rather complex to and honestly quite ugly. In the next section, I therefore show you another library, which is much nicer to use, if you want to detect more complex gestures.

In this example we are going to use the RevEng_PAJ7620 Library to detect 9 gestures. To install this library, open the Library Manager , search for “RevEng PAJ7620”, find the library “RevEng PAJ7620” by Aaron S. Crandall and click on INSTALL:

And here is the example code that uses the RevEng PAJ7620 Library to recognize 9 different gestures:

As you can see, it is very simple. First, we include the library and create the sensor object. In the setup function we initialize serial communication and the sensor. And in the loop function, we read a gesture and the use a switch statement to print out, what gestures was detected.
