A Light Intensity Sensor is used to measure the amount of ambient light in an environment. It converts light levels into an electrical signal, which can be processed by an Arduino to control devices or monitor lighting conditions.

The Light Intensity Sensor works based on a photodiode or a Light Dependent Resistor (LDR). When exposed to light, the resistance of the LDR changes, generating a corresponding voltage signal. The Arduino reads this signal and determines the light intensity.

To connect the Light Intensity Sensor to Arduino, connect the VCC and GND pins to +5V and GND on the Arduino. The A0 pin is connected to an analog input pin for continuous monitoring of light levels.

Interfacing a Light Intensity Sensor with Arduino allows for accurate monitoring and control of ambient lighting. These sensors are widely used in smart lighting, agriculture, and wearable technology. With simple wiring and coding, you can integrate light sensing into your projects effortlessly.

BH1750FVI (or BH1750) is a calibrated digital light sensor IC that measures the incident light intensity and converts it into a 16-bit digital number. The BH1750FVI sensor directly gives digital output .

The sensor output can be accessed through an I2C interface. It can measure ambient light intensity and the measurement unit is Lux. Interfacing this module with Arduino is quite easy.

If you need more help with installing a library on Arduino, read this tutorial: How to Install an Arduino Library

In this tutorial we will learn how to quickly and easily use the GY-30 BH1750 light intensity sensor with Arduino.

To start programming the Arduino, you will need to have the Arduino IDE installed from here: https://www.arduino.cc/ .

Please be aware that there are some critical bugs in Arduino IDE 1.6.6. Make sure that you install 1.6.7 or higher, otherwise this Instructable will not work! If you have not done follow the steps in this Instructable to setup the Arduino IDE to program Arduino UNO! The Visuino: https://www.visuino.com also needs to be installed. Start Visuino as shown in the first picture Click on the “Tools” button on the Arduino component (Picture 1) in Visuino When the dialog appears, select “Arduino UNO” as shown on Picture 2

In Visuino, Press F9 or click on the button shown on Picture 1 to generate the Arduino code, and open the Arduino IDE

In the Arduino IDE, click on the Upload button, to compile and upload the code (Picture 2)

If you power the Arduino UNO module, the Display will start to show a light intensity number that it gets from the Light Sensor.

Note: If you dont have an OLED Display you can just wire the “ListSensor1” pin [Out] to Arduino Serial[0] pin [In] and monitor the Light intensity in Visuino Serial Tab (Picture1)

Congratulations! You have completed your project with Visuino. Also attached is the Visuino project, that I created for this Instructable. You can download it here and open it in Visuino: https://www.visuino.com

The LDR light sensor module is capable of detecting and measuring light in the surrounding environment. The module provides two outputs: a digital output (LOW/HIGH) and an analog output.

In this tutorial, we will learn how to use an Arduino and an LDR light sensor module to detect and measure the light level. Specifically, we will cover the following:

Afterward, you can modify the code to activate an LED or a light bulb (via a relay) when it detects light.

If you prefer a light sensor in its raw form, I suggest exploring the tutorial on the Arduino - Light Sensor .

The LDR light sensor module can be utilized to detect the presence of light or measure the light level in the surrounding environment. It provides two options via a digital output pin and analog output pin.

Since the light sensor module has two outputs, you can choose to use one or both of them, depending on what you need.

Please keep in mind that if you notice the LED status remaining on constantly or off even when there is light, you can adjust the potentiometer to fine-tune the light sensitivity of the sensor.

Now we can customize the code to activate an LED or a light when the light is detected, or even make a servo motor rotate. You can find more information and step-by-step instructions in the tutorials provided at the end of this tutorial.

The below video demo uses the below code. Note that the video shows Arduino Uno R4, but it works identically for Arduino Uno R3:

In this tutorial, let’s learn how to connect BH1750 light intensity sensor with Arduino and display the light intensity values on 16X2 LCD display in Lux Units . So in this article you are going to learn the Overview of BH1750 light sensor, How BH1750 sensor works? and interfacing it with Arduino Microcontroller .

BH1750 is a digital ambient light sensor which measures the light intensity incident on the sensor and converts it into a 16 bit digital number. It doesn’t required any type of converting modules as the sensor itself has an ADC which converts and outputs a digital signal.

BH1750 uses I2C communication protocol to transmit the data which makes it compatible with almost all microcontroller boards. BH1750 directly outputs the measured light in Lux units which is the unit of light intensity.

BH1750 Sensor board contains BH1750FVI IC . When an Ambient light is incident on the sensor the photo diode with a latency nearly equals to human eye absorbs the light and produces an analog voltage signal which is further connected to ADC unit to convert it from analog to digital 16 bit data.

In the next step with the help of two registers data register and time register the light intensity is calculated and transmit the data signal through I2C bus.

This sensor is mainly used in LCD displays, TVs, Monitors and mainly in Mobile displays to automatically adjust the screen brightness according to the outdoor light conditions. This sensor can also used to Turn on/Off the lights.

You might be thinking of LDR(Light dependent Resistor) which works as same but this BH1750 sensor has more advantages like higher accuracy and stability over LDR.

From the above pinout diagram as you can see there are 5 pins. 2 Pins for power supply VCC and GND. Another 2 pins for I2C communication SCL and SDA. And the last one is I2C Address pin which we are not going to use in this tutorial.

As you can see from the above pinout diagram BH1750 power pins VCC and GND are connected to 3.3v and GND pins of Arduino respectively. The I2C pins of BH1750 SDA and SCL are connected to A4 and A5 pins of Arduino respectively.

The power pins VCC and GND of 16X2 LCD display with I2C adapter is connected to 5V and GND pins of Arduino respectively and I2C communication pins SDA and SCL are connected to the same A4 and A5 of Arduino respectively.

Now connect the Arduino to the PC where Arduino IDE is installed to upload the below code. This source code required few libraries which are listed below, you can install them directly through Arduino IDE library manager or you can Download them from the below links and extract them into libraries folder in Documents.

Copy the below code and paste it into Arduino IDE workspace and hit upload button.

After uploading the code you can see the light intensity lux values are displayed on the serial monitor and LCD display module. You can check with any light sources like torch light, flashlight or even sun.

As you can see from the output image that when a light falls on the sensor it shows the intensity of the light on the LCD display connected. Through this values you can create projects like automatic streetlights, Automatic sensor car headlamps and more.
