Metal Detector is a security device which is used for detecting metals which can be harmful, at various places like Airports, shopping malls, cinemas, etc. Previously we have made a very simple Metal detector without a microcontroller , now we are building the Metal Detector using Arduino . In this project, we are going to use a coil and capacitor which will be responsible for the detection of metals. Here we have used an Arduino Nano to build this metal detector project . This is very interesting project for all electronics lovers. Wherever this detector detects any metal near it, the buzzer starts beeping very rapidly.

The following are the components that you would need to build a simple DIY metal detector using Arduino . All these components should be easily available in your local hardware shop.

Whenever some current passes through the coil, it generates a magnetic field around it. And the change in the magnetic field generates an electric field. Now according to Faraday's law, because of this Electric field, a voltage develops across the coil which opposes the change in magnetic field and that’s how Coil develops the Inductance , means the generated voltage opposes the increase in the current. The unit of Inductance is Henry and formula to measure the Inductance is:

When any metal comes near to the coil then coil changes its inductance. This change in inductance depends upon the metal type. It's decreases for non-magnetic metal and increases for ferromagnetic materials like iron.

Depending on the core of the coil, inductance value changes drastically. In the figure below you can see the air-cored inductors, in these inductors, there will be no solid core . They are basically coils left in the air. The medium of flow of magnetic field generated by the inductor is nothing or air. These inductors have inductances of very less value.

These inductors are used when the need for values of few microHenry. For values greater than few milliHenry these are not a suitable one. In below figure you can see an inductor with ferrite core . These Ferrite Core inductor has very large inductance value.

Remember the coil wound here is a air-cored one, so when a metal piece is brought near the coil, the metal piece acts as a core for the air cored inductor. By this metal acting as a core, the inductance of the coil changes or increases considerably. With this sudden increase in inductance of coil the overall reactance or impedance of the LC circuit changes by a considerable amount when compared without the metal piece.

So here in this Arduino Metal Detector Project , we have to find the inductance of the coil to detect metals. So to do this we have used LR circuit (Resistor-Inductor Circuit) that we already mentioned. Here in this circuit, we have used a coil having around 20 turns or winding with a 10cm diameter. We have used an empty tape roll and wind the wire around it to make the coil .

We have used an Arduino Nano for controlling whole this Metal Detector Project . A LED and Buzzer are used as metal detection indicator. A Coil and capacitor is used for the detection of metals. A signal diode is also used for reducing the voltage. And a resistor for limiting the current to the Arduino pin.

Working of this Arduino Metal Detector is bit tricky. Here we provide the block wave or pulse, generated by Arduino, to the LR high pass filter. Due to this, short spikes will be generated by the coil in every transition. The pulse length of the generated spikes is proportional to the inductance of the coil. So with the help of these Spike pulses, we can measure the inductance of Coil. But here it is difficult to measure inductance precisely with those spikes because those spikes are of very short duration (approx. 0.5 microseconds) and that is very difficult to be measured by Arduino.

So instead of this, we used a capacitor that is charged by the rising pulse or spike. And it required few pulses to charge the capacitor to the point where its voltage can be read by Arduino analog pin A5. Then Arduino read the voltage of this capacitor by using ADC. After reading voltage, the capacitor quickly discharged by making capPin pin as output and setting it to low. This whole process takes around 200 microseconds to complete. For better result, we repeat measurements and took an average of the results. That’s how we can measure the approximate inductance of Coil . After getting the result we transfer the results to the LED and buzzer to detect the presence of metal. Check the Complete code given at the end of this Article to understand the working.

Complete Arduino code is given at the end of this Article. In the programming part of this project, we have used two Arduino pins, one for generating block waves to be fed in Coil and second analog pin to read capacitor voltage. Other than these two pins, we have used two more Arduino pins for connecting LED and buzzer.

You can check the complete code and Demonstration Video of Arduino Metal Detector below. You can see that whenever it detects some metal the LED and Buzzer start to blink very fastly.

Very nice project , I have successfully made it using arduino uno r3, but the only problem I have experienced is it can't detect small objects like small leds, alligator clips, .. Is it okay that I used the built in USB-B Port of arduino connected to 5k Mah power bank as power supply?

I have a UNO R3 too, is there any difference in circuit and code..Please can you help me through if there is any difference.

please send me the correct code i have check the above program but it shows some error. so please mail the code sir.

I could not able to able get the exact output. My LED and buzzer are blinking as such in a some random manner. I suspect my output is not right coz, even if i keep the metal very close to it, it is not working. Please help me ..... Thanks in advance.

were you able to solve it , i am facing the same problem , please help if u r able to solve it

Can you pls help me? Can you send me the picture of the breadboard, wires and other components in it?

I m using coil , not wire it help me or not...if it can't help me which wire I used breadboard wire... Plz tell me ...plz

Coil should have also worked, just make sure if it is enameled!! The wire used here is normal breadboard wire

hi. can i use different diameter of tape to measure the sensitivity of the search coil? or it will effect the faulty of circuit?

i made the circuit, but the buzzer always makes noise and when a metal is here, nothing happens. So it doesn't work. Help please !

I was going to do this for a school project and was wondering if the size of the tape thing that you wrap the wire around could effect the ability to detect metals?

hey guys !pls reply I am unable to find a 10nf capacitor and somebody told me to use 10pf capacitor.so,tell me will that go with the metal detector ?will it work?pls...reply fast.. circuit digest has helped me a lot with my project .. just need one more help .. pls reply..

There are many ways of defining capacitors. They are usually defined as nanofarads, picofarads, and microfarads. Essentially it's the same thing, with the decimal place in a different location.

The idea is to end up with a number that makes sense (i.e., that isn't too large or too small).

The capacitor may also be labelled with a three number code. In your case you would want a capacitor labelled 103.

In such a case the capacitor is measured in picofarads. The first two digits represent the first two values for the capacitor, and the 3 represents the number of extra zeros.

WE ARE DOING A METAL DETECTOR PROJECT FOR MY M.SC COURSE BUT YOUR CODE DOES NOT SUPPORT FOR THIS PROJECT SO I REQUEST YOU TO PLEASE SEND US CORRECT CODE. THANKING YOU

why is this circuit not working all instructions are followed but not work so how can we follow you?

how can the range of it can be increased such that it can be used for searching the metal objects buried inside soil of about 1 m range..? thanks in advance

can i wound the copper wire as a coil around the tape roll and if i disconnected the arduino from pc how it works can you explain me

After an initial mistake (wrong capacitator, realized reading comments...I am a Pharmacist after all ) works perfectly.

Is there any chance you could send me a picture of your breadboard connections please
