Arduino Music Reactive LED — Embedded System & Circuit Implementation

A music-reactive LED circuit is a simple electronic circuit that responds to varying sound levels, usually, of the rhythmic melody from nearby playing music & displays the changing intensity level of the sound signal in the form of blinking LEDs. It is a common circuit usually used for decorative purposes in places such as ceremonies, clubs & advertisements. So, in this project, we are going to design a simple Music Reactive LED circuit using an Arduino Nano Micro-controller.

The Arduino Nano Microcontroller is a tiny, reliable, durable, and breadboard-friendly Microcontroller board based on the ATmega328p model. On a functional scale, it is pretty much similar to the Duemilanove model, but in a slightly different package. It has no DC power jack like other models & requires a Mini-B USB cable to be powered by a laptop or PC.

5) Connect the Arduino Nano Controller & the sound sensor module on the PCB board. After that, upload the source code to the Arduino

The working of this circuit is pretty simple. An AC audio Signal is taken as input by the KY - 038 sound sensor module. The module feeds the analog out at pin A0 of the controller & the digital out to pin D8 of the microcontroller. Now to the working of the controller, D8 is defined as the sound sensor input while D9 is defined as the LED strip out using the pin Mode() command. Now, using the digital Read() command, each time the sound sensor detects a sound (status sensor == 1) it sets the pin D9 of the controller to high using Digital Write().

When D9 is set to high, the outDC signal acts as a control signal to the base of the BC547 transistor. The collector output of the transistor goes to the Gate of the IRFZ44N transistor. I RFZ44N is known for its high drain current and low switching time. It also has a low Rds value which will help in increasing the efficiency of switching circuits. The Drain output of the transistor then triggers the LED strip corresponding to the input sound signal.

Introduction Photography enthusiasts are always on the lookout for ways to improve their skills and take better shots. One area that can gre…

Introduction Controlling WS2811 addressable LED strips with Arduino Bluetooth control using an Android app opens up a world of possibilities…

Introduction In modern automation, many times you have noticed that almost every car has a reverse parking sensor to observe any hurdles in…

In this tutorial, we are going to make a "Reverse Car Parking Sensor Circuit". Let's say, we have a tiny space for parking vehicles and need…

Are you getting bored while making intense electronic projects and do you want to make yourself relaxed by making some fun projects? We are here for you with some interesting projects of music-reactive LED strips. Nowadays, LED strips are widely used for decorating purposes. For example, you have also observed them at birthday parties, weddings, and other different events. But, do you know that you can control those LED strips with the sound of music? We are sure you have noticed the lightning that gets reactive on the sound of music. In this tutorial, we are trying to make the same thing. Hence, In this tutorial, we are going to make a "Music reactive LED Strip". For better quality and reliable use, we suggest you make this circuit on the printed circuit board.

LED strip lights are greatly used in creativity and for artistic purposes. It consists of many light-emitting diodes on a flexible printed circuit board, having a wide range of colors and brightness. Therefore, you may also have seen this in mirrors, picture frames, stairways, TV screens, decorative rooms, etc. The strip lights require very low DC voltage to operate. It has an adhesive backing that enables easy installation. Mostly offers RGB colors and is used for decorative applications. The LED strip includes the cutlines in it, located at every one or two inches far, which makes it easier for the user to cut it if needed.

Connect the Music reactive LED Strip according to the diagram given in this circuit. write the code in the Arduino IDE and upload the code in Arduino. Now, play the music on any music player or mobile phone and place it near the LED strip. The sensor connected with the Arduino detected that music. Since the sensor is wired with the Arduino, therefore, Arduino takes that signal and works according to the code. Arduino gives that signal to the transistor, which simply drives the MOSFET. As a result, the LED strip starts working accordingly.

Introduction Photography enthusiasts are always on the lookout for ways to improve their skills and take better shots. One area that can gre…

Introduction Controlling WS2811 addressable LED strips with Arduino Bluetooth control using an Android app opens up a world of possibilities…

Introduction In modern automation, many times you have noticed that almost every car has a reverse parking sensor to observe any hurdles in…

In this tutorial, we are going to make a "Reverse Car Parking Sensor Circuit". Let's say, we have a tiny space for parking vehicles and need…

Using an Arduino Nano , the sound reactive LED lights project is the best electronic project for a hobby electronic enthusiast. The LED lights will be on and off based on the music or sound. This project uses a condenser microphone to detect the audio signals and dynamically adjust the LED brightness and patterns based on the intensity and frequency of the sound. Whether it’s for creating an engaging music visualization setup, enhancing home decor, or building an interactive art installation. This project’s circuit diagram and programming code are given in this article.

In this given sound reactive LED light circuit, a BC547 transistor is used to amplify the audio signal received from the condenser microphone. The amplified audio signal will be detected by the Arduino nano through the Pin A5.

The collector pin of the transistor is connected to the A5 of Arduino Nano. The emitter pin is connected to the ground connection. A 100kΩ resistor is placed between the collector of the transistor and the audio signal input to regulate the current flow.

The 10kΩ resistor is connected between the transistor’s collector pin and ground to stabilize the input signal. A 104 pf disc capacitor is used to filter unwanted noise from the microphone input.

The microphone’s one terminal is connected to the 5V supply voltage through a 10kΩ resistor. The ground pin of the microphone is also connected to the common ground of the circuit.This circuit will work when the condenser mic detects the audio signals. Then, the signal is amplified by the transistor, and it is transferred to the Arduino. The Arduino then turns on and off the WS2812 LED strip based on the audio signal.
