Arduino as PLC is an open-source project that demonstrates how to use Arduino boards as a low-cost, efficient alternative to traditional PLCs (Programmable Logic Controllers) for industrial automation and control. This project enables hobbyists, engineers, and DIY enthusiasts to build their own automation systems using Arduino.

The Arduino as PLC project provides a cost-effective solution for industrial automation, enabling the creation of programmable logic controllers using an Arduino board. Traditional PLCs can be expensive and complex, but by using Arduino, hobbyists and engineers can design custom control systems that are affordable and scalable.

This project supports various industrial applications, from home automation to factory control systems, and provides an open-source platform that can be modified according to your needs.

For a detailed guide and technical documentation on how to build and implement each project, visit the Wiki .

This project is licensed under the MIT License - see the LICENSE file for details.

We welcome contributions to the Arduino as PLC project! If you have ideas, improvements, or want to help others in the community, please check out the CONTRIBUTING guidelines.

PLCs (programmable logic controllers) are used within the operational technology (OT) space, such as in the industrial control systems (ICS) that manage manufacturing, energy generation, and robotics. PLCs are often integrated into SCADA systems, where a PLC is used to monitor inputs (e.g. temperature) and adjust outputs (e.g. motors) of a control system.

Most PLCs, made by the likes of Siemens and ABB, cost thousands of pounds to buy - not particularly beginner-friendly. However, I recently came across the OpenPLC Project , which lets you turn (among other things) an Arduino into a PLC!

I found a great pair of videos on YouTube, walking you through the above steps. If these videos didn’t exist, I’d make my own, but as they already do - give credit where credit is due!

All of the below projects (except the last one) use the same basic physical setup. I was using my large breadboard for my myopia measurer , and didn’t want to disassemble it. Fortunately my kit came with a tiny extension board, and as these projects only need one or two push-buttons and an LED, it was plenty for my needs. I ran out of red wires so orange represents +5V.

So what are you looking at? There’s an LED between the Arduino output (white wire) and ground, and there are two push-buttons, with one side connected to live (+5V), the other side connected to the Arduino inputs (blue wires) with pull-down resistors to ground. The pull-down resistors ensure that, when not pressed, the push-button provides a logic 0 (i.e. off) to the Arduino.

The functionality of this circuit is simple. Press the Start button, and the LED starts. It will stay on (latched) until the Stop button is pressed. This turns a pair of push-buttons into an on-off switch.

You can see how it works, in stages, by the following diagram, courtesy of Inst Tools . Blue is activated.

This is what it looks like in the OpenPLC Editor. Nice and simple. The location values are defined by OpenPLC, and are explained within the Arduino page on their website (link above).

The functionality is the same as the previous one, except a single button is used for the latching on and off. This is even more like a switch!

This ladder logic came from mayurhaldankar.wordpress.com , via PLC Academy . I added the emergency stop - it is simply a normally-closed push-button (PB1) on the same rung as the coil.

These are the variables. Note M0 and M1 have no physical representation, and hence no location.

Using the OpenPLC simulator, you can see the operation from the following steady states. Note this is different from the diagram from Inst Tools above, as that is done rung-by-rung, whereas the below is done state-by-state. Note in particular the states of the coils M0 and M1 in relation to the “true” output Q0 (in my circuit, the LED).

Timers are very commonly used in OT, such as turning a pump on 30 seconds after a motor has started, or turning a fan off five minutes after an engine has stopped. Basic ladder logic is constructed of contacts and coils, but there are also function blocks, of which on-timers and off-timers are among the most common.

This simply turns the LED on two seconds (the T#2000ms) after the button is pressed, and turns it off two seconds after the button is pressed a second time.

The idea of this design is to keep a variable within a threshold range (for example, water temperature). In reality the output would be the input (i.e. it would have feedback), and it would use more a complex control system (e.g. PIDs), but this is just a simple experiment using comparative function blocks.

In this design, if it is within the threshold range, the “ideal temperature” light (green LED) comes on. If it’s below, the “increaser” comes on (e.g. turn on a heater - simulated by the red LED). If it’s above, the “decreaser” comes on (e.g. turn on a cooler - simulated by the blue LED). Note the NC contactor relating to the ideal_temp coil - in other words, if it’s within the ideal range, neither the increaser or decreaser can function.

Due to how OpenPLC works, the input is an (unsigned) 16-bit integer. This means the value range is 0 to 65536 (2^16). Obviously this doesn’t relate well to water temperature! For this experiment, let’s say 0 is 0°C and 65536 is 100°C. The optimum temperature range is 60-70°C - perfect for your cup of tea or coffee. This means 60% and 70% of 65536, or the lovely round numbers of 39322 and 45875 (both to zero decimal places).

Here it is in action. Note this uses a different circuit to the other examples, as it has three LEDs and a potentiometer.

Arduino Vs PLC- Hello and welcome back to Electronic clinic . In this article, we are going to take a look at the similarities and differences between Arduino and PLC . As you guys know I have been using the Fatek PLC FBS-14 in different projects as this version of the PLC is ideal for beginners, because it’s cheap. All the PLCs shares the same functionalities, the only difference can be in the prices, inputs and outputs, etc. So, I will do the comparison between the Arduino and Fatek PLC FBS-14. Unlike the PLC, Arduino is also the most powerful controller board, you can even build your own PLC using Arduino. In the end I will share with you the “ PLC Arduino ARDBOX” this is a PLC developed using the Arduino board. We will talk about the PLC Arduino ARDBOX in detail. But for now, let’s concentrate on the Arduino Vs PLC . Without any further delay, let’s get started!!!

*Disclosure: These are affiliate links. As an Amazon Associate I earn from qualifying purchases.

Arduino is an open-source electronic platform; this hardware allows anyone to complete automated electronic projects at low cost and in very little time making the Arduino ideal for prototyping. on the other hand, a PLC or programmable logic controller is an industrial computer that has been reinforced and adapted to control manufacturing processes. Let’s begin this comparison, let’s first take a look at some of the similarities between the Arduino and PLC.

both are programmable both can continuously monitor the status of input signals and make decisions based on a custom program to change the status of devices connected to the output, so both can be used in automation. the language used to program an Arduino is basically a set of C and C++ functions on the other hand a PLC can use five different languages, the five programming languages are ladder diagram, function block diagram, structure text, instruction list, and sequential function chart.

The purpose of this ladder logic program is to control the outputs Y0, Y1, …, y5 when the coil contacts M0, M1, …, M5 are activated. It’s very simple. If you write the same program for the Arduino it will take a lot of time and you will need to write multiple lines of code.

Just look at the Arduino code, the purpose of this code is to turn ON and turn OFF an LED at a regular interval of 1 second. The same thing can be done in PLC in only 1 line or maximum 2 lines using the LADDER Logic Programming . For the best understanding checkout my PLC and Arduino based projects.

So in languages, the advantages for the PLCs with most PLCs , we can update the program in a short period of time. on the other hand, if there is a problem there are a variety of options in the system that we can configure like real time tables, real-time charts, real-time ladder logic view, etc, but help us to monitor all the variables in the i/o, all of these options facilitate the troubleshooting process the ladder logic and other languages, that the plc has made it very intuitive to make a change to the Arduino . It takes more time especially if there is a new person working with the system. It is more difficult to figure out C, and C++ instructions to display the data collected from the Arduino IO. We could use an external screen however troubleshooting the system, with the Arduino is more difficult. Here the advantage is also for the PLC; on the PLCs, I/O modules can be added and removed as needed. If any of the idle modules breaks that module is simply replaced, on the other hand, the I/O is embedded in the Arduino board if the I/O section of the Arduino is broken, we have to replace the entire board IO adaptability, and flexibility winner the PLC. When it comes to price the Arduino board and all components are cheaper than PLCs . The PLC’s are certified to work and perform under industrial conditions where there are high temperatures, noise, vibrations, and gas emissions etc. PLC’s have a robust designed to work in industrial environments.

1. Executive Abstract and Engineering Problem Formulation for Arduino Plc Alternative

The continuous development of embedded automation, physical computing, and real-time instrumentation requires reliable hardware architectures capable of processing sensor telemetry with sub-millisecond determinism. The development of Arduino Plc Alternative addresses manual operational bottlenecks by pairing analog/digital sensory acquisition with low-overhead firmware execution on the ATmega328P Microcontroller (Arduino Uno / Nano). Conventional automated solutions frequently suffer from ground loops, voltage sag under inductive transients, and unhandled watchdog timer resets. This investigation resolves these failure modes by combining physical galvanic isolation, hardware RC filtering, and an interrupt-driven state machine architecture designed to meet university capstone and industrial deployment standards.

2. Microcontroller Architecture, Memory Allocation and Clock Distribution
