In this Interesting Arduino Project, You will learn how to measure Wind speed by interfacing Adafruit Anemometer with Arduino and display the speed of the wind on LCD display module or OLED display. Generally when some NEWS channels shows the weather forecast update, you can notice that they show some device which has semi spherical cups rotates according to the speed of wind which is called Anemometer and there is an arrow on its top which moves according to the wind direction it is called wind vane.

Through this article we will explain what is Anemometer, how Anemometer works, types of Anemometers and how to interface it with Arduino and a working program code to calculate and display the wind speed on serial monitor and LCD Display module .

Below are the all required components which are used in building wind speed measuring system project or Arduino Anemometer project .

The anemometer, also known as an anemograph, is a meteorological instrument whose task is to measure the average speed of wind. Not only wind it has the ability to measure the speed or velocity of any gas flow through atmosphere, Closed vents or even through pipes . It has various applications in various fields where air is the parameter in their work or activity.

Anemometers measure the instantaneous speed of the wind, but the gusts of wind distort the measurement, so that the most accurate measurement is the average value of measurements taken at 10-minute intervals.

There are few different types of anemometers from those the rotating cup anemometers are used as an industry standard, whose principle and build gives stability and ease of use even in high speed winds. Even in rotating cup model there are types, when winds flows across the cups, they rotate according to the speed. So, some will measure the speed by counting the number of rotations of the cups while other will generate certain voltage proportional to the speed of the wind.

It is a Rotating cup Anemometer which is based on hall effect principle and contain a hall effect sensor which generates analog voltage when the cups rotate. By measuring the Analog voltage which is linear to the wind flow across the device we can calculate the actual wind speed. It can measure the wind speeds upto 32.4 meters/ second which are high velocity winds .

This device works with 7v to 24v DC supply , It is rugged and has high quality material all over its body to sustain and withstand from harsh weather conditions for long time. Even its plug pins are made from anti corrosive materials and protected in a metal enclosure.

Its output analog voltage ranges from 0.4V at 0 meters/sec to 2V at 32.4 meters/sec.

Even though the plug has 4 pins inside but from the above pinout image you can notice there are only 3 wires. Brown wire for VCC power, Black wire for GND and Blue wire for Data or Output. You can connect and use it with most of the microcontrollers which has pins to read analog input voltage.

Related article: Air Quality monitor using Arduino for indoor and outdoor pollution monitor

Connect all the required components according to the below circuit diagram to measure the speed of wind on Arduino LCD display.

Arduino Nano is Powered from a 9V battery or an adapter by connecting +ve wire to VIN and -ve wire of supply to GND pin of Arduino. For this project you an use Arduino UNO board also

As you can see from the above circuit diagram 16X2 LCD display is powered from Arduino 5V and GND pins. And for I2C connection SDA and SCL of LCD are connected to A4 and A5 of Arduino Respectively. For more details on connecting LCD display read this article: Interfacing LCD Display with Arduino in detail

The Anemometer Brown wire is connected 9V and Black wire is connected to GND. Blue wire which is Data is connected to Arduino pin A0.

To interface this setup with OLED display instead of LCD refer this Article: Interfacing OLED display with Arduino

Build a Professional Wind Speed Meter with PCBWay’s Complete Manufacturing Services

Transform your anemometer and Arduino project into a weather-ready instrument with PCBWay’s integrated PCB fabrication and 3D printing solutions. Create a reliable wind monitoring system that combines accurate electronics with durable, weather-resistant housing.

Custom PCB Integration: Design a unified board that seamlessly connects your Arduino, anemometer interface, display unit, and data logging components. Our professional SMT assembly ensures precise soldering of sensitive analog circuits for accurate RPM-to-wind speed conversion, while optimized power management provides stable operation in outdoor conditions.

Weather-Proof 3D Printed Enclosure: Create custom housings using our advanced 3D printing services with UV-resistant ASA or waterproof PETG materials. Design specialized mounting brackets for secure anemometer attachment, cable glands for weather protection, and optimized ventilation to prevent moisture buildup while maintaining accurate airflow measurements.

Launch Your Weather Station Project Today Upload your PCB designs and enclosure models to receive instant quotes and expert DFM feedback. Start Building Now with PCBway.com

Now its time to upload the code. connect Arduino to a PC where Arduino IDE is installed. Choose the board as Arduino NANO or which ever you use and select the correct port from the Tools menu. Install required libraries from the built in Library manager or you can download the latest version from the below links

Next copy the below code and paste it in IDE workspace and press upload button. That’s it the code will be uploaded.

After uploading the code you can see the Analog value, Analog voltage, wind speed in meters/sec and meters/hr on serial monitor.

From the below table the you can observe how the wind speed is classified from its calm(minimum) to hurricane levels(maximum). Our DIY Arduino Anemometer can measure up to strong temporary winds.

In this guide, you’ll learn how to use an anemometer with the Arduino board to measure wind speed. We’ll cover how to power and connect the sensor to the Arduino and write a simple code to get wind speed values in different units.

An anemometer is a device that allows us to measure wind speed. It is commonly used in weather stations.

Using this sensor is quite easy. It outputs an analog signal, whose voltage is proportional to the wind speed. We’re using an anemometer with three cups like the one in the picture below.

Depending on the manufacturer and model, the anemometer may have different characteristics. For example, these are the characteristics of the anemometer used in this guide:

This means that when the analog signal is 0, the wind speed is 0. However, in my case, I noticed that when the anemometer was not moving, the output voltage was 0,054V and not 0V.

So, I consider this to be the lowest value measured when the sensor is not moving. I recommend you do the same and figure out the minimum value read from the sensor using a multimeter.

These details might be different for your specific model . So, you need to take that into account when converting the analog signal to wind speed.

The anemometer we’re using requires an input voltage of at least 12V. So, you can’t power it directly from the Arduino, you need an external power source.

We’re powering the sensor using a 12V power adapter and connecting it to the anemometer using a power jack. You can use any other suitable power source.

Wiring the sensor to the Arduino is quite simple. You just need to connect the data signal to an analog pin of the Arduino and connect the GNDs together.

The following code reads the analog signal from the anemometer and converts it into wind speed.

You can upload the following code to your Arduino board. You may need to modify some of the variables depending on the parameters of your anemometer.

First, define the pin where you’re reading the sensor (in our case A0), the minimum and the maximum output voltage of the sensor, and the maximum wind speed.

These are the parameters for our sensor. Yours might be different. When the sensor is not moving, it outputs a voltage of 0.054V, so we consider that the minimum value.

Then, we have the conversion factors to convert the wind speed from m/s to km/h and mph.

First, we read the value on the ADC pin and convert it to a voltage value. The maximum value read on the Arduino ADC pin is 1023 that corresponds to 5V. So, we can convert the value to a voltage using the following line:

Then, we have the following condition to check if the values read are within the defined range.

Next, we can easily map the obtained voltage to a wind speed value (alternatively, you can use the Arduino map() function).

Upload the code to your Arduino board. Make sure you have the sensor wired and powered properly.

Spin the sensor to mimic some wind, and see the values being printed in the Serial Monitor every second.
