Abstract — Bradycardia Alarm Neonatal

infants during NICU monitoring, in order to propose an early bradycardia detector which is based on a decentralized fusion of three detectors. The main objective is to improve automatic detection under real-life conditions without altering performance with respect to that of a monitor commonly used in NICU. We used heart rate lower than 80 bpm during at least 10 sec to define bradycardia. With this definition we observed a high rate of false alarms (64%) in real-life and that 29% of the relevant alarms were not followed by manual interventions. Concerning the proposed detection method, when compared to current monitors, it provided a significant decrease of the detection delay of 2.9 seconds, without alteration of the sensitivity (97.6% vs 95.2%) and false alarm rate (63.7% vs 64.1%). We expect that such an early detection will improve the response of the newborn to the intervention and allow for the development of new automatic therapeutic strategies which could complement manual intervention and decrease the sepsis risk.

Sensor Interfacing & Analog Front-End Conditioning

Respiration is unstable in the newborn, especially in the preterm infant. In these infants, apnea is a frequent phenomenon, which can be isolated, associated with hypoxemia or with a combination of hypoxemia and bradycardia. The current clinical definition of apnea or cardio-respiratory events in this context is not very precise and remains difficult to use in practice. An apneic spell is defined by the American academy of pediatrics as a cessation of breathing for 20 seconds or longer or a shorter pause accompanied by bradycardia ( \(<100\) beats per minute), cyanosis, or pallor 1 . Those latter combined events may compromise brain oxygenation and tissue perfusion, especially when hypoxemia is followed by bradycardia 2 . The long-term impact of this intermittent hypoxemia during early postnatal life remains to be determined, but cardiorespiratory events have been evoked to potentially impact the risks of retinopathy, growth alteration, sleep-disordered breathing, and neurodevelopmental impairment 3 , 4 , 5 .

Bio-Signal Waveform Analysis & Simulation Findings

In Neonatal Intensive Care Units (NICU), preterm infants undergo continuous monitoring through polygraphic recordings, to detect cardiorespiratory events and to initiate quick nursing actions, such as manual stimulation, mask ventilation and sometimes intubation. In those clinical settings, nurse interventions and treatment decisions are mostly based on oxygen saturation (SaO2) and heart rate alarms 6 . The detection of apneas through analysis of chest impedance waveform remains unreliable with reported false alarm rates of more than 60% and lack of detection in more than 25% of apneas lasting more than 10 s 7 , 8 . The pulse oximeters also exhibit around 20% lack of detection and more than 50% false alarm rates 9 .
