Abstract — Oxygen Blender Control
Creative Commons Attribution (CC BY) license ( https://creativecommons.org/licenses/by/4.0/ ). Respiratory diseases are among the leading causes of death globally, with the COVID-19 pandemic serving as a prominent example. Issues such as infections affect a large population and, depending on the mode of transmission, can rapidly spread worldwide, impacting thousands of individuals. These diseases manifest in mild and severe forms, with severely affected patients requiring ventilatory support. The air–oxygen blender is a critical component of mechanical ventilators, responsible for mixing air and oxygen in precise proportions to ensure a constant supply. The most commonly used version of this equipment is the analog model, which faces several challenges. These include a lack of precision in adjustments and the inspiratory fraction of oxygen, as well as gas wastage from cylinders as pressure decreases. The research proposes a blender model utilizing only dynamic pressure sensors to calculate oxygen saturation, based on Bernoulli’s equation. The model underwent validation through simulation, revealing a linear relationship between pressures and oxygen saturation up to a mixture outlet pressure of 500 cmH 2 O. Beyond this value, the relationship begins to exhibit non-linearities. However, these non-linearities advancement in the field, addressing the scarcity of work focused on this essential equipment crucial for saving lives.
Sensor Interfacing & Analog Front-End Conditioning
The COVID-19 pandemic exposed the fragility of healthcare systems worldwide, particularly regarding resource scarcity and the management of critically ill patients. The overwhelming demand for mechanical ventilation, a life-saving technology for severe respiratory cases, highlighted critical limitations in equipment availability and performance. One crucial element in these ventilators, the air–O2 blender, proved susceptible to challenges like imprecise adjustments, flow sensor limitations, and efficiency decline with cylinder pressure depletion. These issues directly impacted patient care and outcomes, particularly during the peak of the pandemic when resources were most stretched.
Bio-Signal Waveform Analysis & Simulation Findings
Instances like the one witnessed in the state of Amazonas, Brazil served as an illustration of the severity of the situation in the absence of adequate resources or planning. The critical shortage of oxygen cylinders throughout the state marked the peak of the ensuing chaos, resulting in multiple fatalities among hospitalized patients [ 1 , 2 , 3 ].
