Getafe,Madrid, Spain A microstructure-sensitive fatigue life prediction framework based on CP- FFT is proposed to study SLM fabricated Hastelloy-X. The microstructure enters in the model through the shape, size and orientation distributions of grains in the RVEs, which are generated from experimental EBSD data.
Sensor Interfacing & Analog Front-End Conditioning
Figure 1: Diagnostic Medical Waveform & Bio-Potential Clinical Trace for Simulia Abaqus Fatigue Implant The framework has been applied to specimens built in two diIerent direc- tions with diIerent polycrystalline microstructures and is able to accurately predict their fatigue life, using just two experiments for calibration. The model reproduces the better fatigue performance found experimentally at high stresses for samples built in transverse direction, identifying the origin of this anisotropy in grain aspect ratios.
Bio-Signal Waveform Analysis & Simulation Findings
Hastelloy-X is a nickel-based superalloy, primarily strengthened by adding solute elements W, Cr, and Mo [1, 2] which shows excellent oxidation and corrosion resistance at elevated temperatures, making it suitable for gas tur- bines and jet engine parts. Moreover, the alloy shows good formability and weldability, making it an ideal candidate for additive manufacturing fabrica- tion, mainly using a selective laser melting (SLM) route .
