Abstract — Wheelchair Pressure Relief Sensor
and wheelchair-bound veterans are just the beginning. Materials engineers are developing new fabric sensors and a customized wheelchair system that assesses and automatically eases pressure at contact points to prevent injuries from developing in the first place.
Sensor Interfacing & Analog Front-End Conditioning
“We have three key issues happening: First, continuous pressure. Second, moisture, because when you're sitting in the same spot, you tend to sweat and generate moisture. And third is shear. When you try to move somebody, the skin shears. That perfect combination is what causes pressure injuries,” said Sundaresan Jayaraman , professor in the School of Materials Science and Engineering (MSE). “We believe we have a solution to the perfect storm of pressure, moisture and shear, which means the user’s quality of life is going to get better.” Sundaresan Jayaraman (left) looks at pressure data from fabric sensors he developed with Sungmee Park, who is seated in their prototype wheelchair system. (Photo: Candler Hobbs) With Principal Research Scientist Sungmee Park , Jayaraman has designed fabric with a network of embedded sensors that covers the seat of a wheelchair. Conductive material is woven into the textile, and it’s washable without degrading the sensors.
Bio-Signal Waveform Analysis & Simulation Findings
Data about pressure and moisture from the sensors feeds into a processing unit that uses artificial intelligence algorithms to identify trouble spots in real time and selectively raise or lower a series of actuators under the wheelchair seat to relieve pressure. That has the advantage of eliminating any shearing forces on the skin that come from sliding against the seat.
Scope & Clinical Applications
