DIGITAL-FILTER-DESIGN COMPANY : CODETECH IT SOLUTION NAME : TANUSHREE M M INTERN ID : CT06WG114 DOMAIN : VLSI MENTOR : NEELA SANTOSH DESCRIPTION : This repository presents the design and simulation of a Digital Finite Impulse Response (FIR) Filter using Verilog HDL, developed and verified through Cadence Virtuosoβ€”an industry-standard platform for custom digital and mixed-signal IC design. FIR filters are fundamental components in digital signal processing (DSP), widely used in applications like audio processing, communication systems, image enhancement, and more. The purpose of this project is to implement a simple, yet practical FIR filter in Verilog, simulate it in Cadence Virtuoso, and analyze its performance with respect to time-domain filtering behavior. Project Overview The FIR filter implemented here performs linear convolution on digital input data with a fixed set of coefficients (taps). The filter is designed to operate on a stream of input samples, apply a weighted sum using the coefficient values, and generate a filtered output. This project focuses on synchronous, clocked operation, making it suitable for integration into hardware-based DSP systems. FIR Filter Design Details Key Parameters: Filter Type: Low-pass (can be customized) Number of Taps: Configurable (default: 4-tap) Data Width: 8-bit input/output Coefficient Width: 8-bit signed Clocked Operation: One output per clock cycle after pipeline fill Signed Arithmetic Support: Supports negative and positive coefficient values Modules: task4.v: Main Verilog module implementing the FIR logic task4_tb.v: Testbench for functional verification with test input samples coefficients: Defined inside the module or can be loaded from a memory initialization file (MIF) Simulation in Cadence Virtuoso The filter was designed and verified using Cadence Virtuoso: RTL Design: Verilog HDL code was entered through Virtuoso's digital design environment Simulation Environment: Cadence ADE (Analog Design Environment) was used to simulate testbenches Waveform Analysis: Output waveforms were examined to confirm the filter’s frequency response and time-domain behavior Pipelined Structure: Implemented optional pipelining for improved timing performance Features & Learning Objectives Understand the principles of FIR digital filtering Implement MAC (Multiply-Accumulate) operations using Verilog Create and verify hardware-implementable DSP modules Analyze filter behavior through Cadence’s waveform viewer Explore fixed-point arithmetic and precision limitations in digital filters Use Cases Audio signal filtering (noise reduction, smoothing) Sensor data processing Preprocessing in ADC/DAC systems Embedded DSP for FPGAs or ASICs How to Use the Project Open Cadence Virtuoso Import or create a new cell with the task4.v module Add the testbench (task4_tb.v) and connect clock, reset, input data, and output Simulate using ADE and observe the output waveform (Optional) Modify coefficients or number of taps for custom filtering behavior MATLAB: Run the code given in FIR_MATLAB, the output will display as given below. Future Enhancements Load coefficients dynamically via memory file Add support for parameterized filter length and bit-width Implement filter coefficient generator from MATLAB Integrate with FFT/IFFT modules for advanced DSP processing Test on real-time signal data streams CODE : OUTPUT : MATLAB OUTPUTS :

This repository presents the design and simulation of a Digital Finite Impulse Response (FIR) Filter using Verilog HDL, developed and verified through Cadence Virtuosoβ€”an industry-standard platform for custom digital and mixed-signal IC design. FIR filters are fundamental components in digital signal processing (DSP), widely used in applications like audio processing, communication systems, image enhancement, and more.

The purpose of this project is to implement a simple, yet practical FIR filter in Verilog, simulate it in Cadence Virtuoso, and analyze its performance with respect to time-domain filtering behavior.

Project Overview The FIR filter implemented here performs linear convolution on digital input data with a fixed set of coefficients (taps). The filter is designed to operate on a stream of input samples, apply a weighted sum using the coefficient values, and generate a filtered output.

This project focuses on synchronous, clocked operation, making it suitable for integration into hardware-based DSP systems.

coefficients: Defined inside the module or can be loaded from a memory initialization file (MIF)

Simulation in Cadence Virtuoso The filter was designed and verified using Cadence Virtuoso:

RTL Design: Verilog HDL code was entered through Virtuoso's digital design environment

Simulation Environment: Cadence ADE (Analog Design Environment) was used to simulate testbenches

Waveform Analysis: Output waveforms were examined to confirm the filter’s frequency response and time-domain behavior

2-Tap FIR Filter Circuit Project Overview This project involves the design and implementation of a 2-Tap Finite Impulse Response (FIR) Filter for signal processing applications. The filter is designed using digital signal processing techniques to achieve efficient signal processing with minimal power consumption.. Objectives To implement a simple digital filter with low complexity. To achieve basic signal smoothing using past and current inputs. To use Cadence Virtuoso for circuit implementation and testing. Results and Conclusion The 2-Tap FIR filter was successfully designed and implemented in Cadence Virtuoso, demonstrating effective noise reduction and signal smoothing capabilities. The linear phase response makes it ideal for applications such as speech processing, biomedical signal enhancement, and digital communication systems. Repository Structure 2-Tap-FIR-Filter │── README.md (This file) │── Schematic Images │── Result Images Future Improvements Extending the design to a higher-order FIR filter with optimized coefficients. Implementing a hardware-efficient architecture using FPGA or ASIC design methodologies. Analyzing power consumption and optimizing for low-power VLSI design. Download & Access Project files can be accessed at: πŸ”— 2-Tap FIR Filter Files

1. Circuit Architecture, Design Objectives and Specifications for Filter Design Cadence

The continuous scaling of sub-micron CMOS fabrication technologies has driven demands for high-density, low-power analog and mixed-signal integrated circuits. The implementation of Filter Design Cadence addresses critical constraints in open-loop gain, unity-gain bandwidth (UGB), phase margin, and silicon area utilization. Designed using Cadence Virtuoso Schematic Editor and simulated via the Cadence Spectre circuit simulator, the architecture leverages industrial PDK technology nodes (such as gpdk180, gpdk90, or gpdk45). Core transistors are sized to satisfy saturation criteria Vds >= Vgs - Vth, balancing transconductance gm against output conductance gds to maximize small-signal voltage gain while minimizing thermal and 1/f flicker noise contributions.

2. Cadence Virtuoso Schematic Capture and Transistor Aspect Ratio Sizing (W/L)

Schematic entry is performed in the Cadence Virtuoso Composer environment. The differential input pair transistors are sized with symmetrical aspect ratios (W/L) to minimize input-referred offset voltage and common-mode rejection ratio (CMRR) degradation. Active current mirrors provide high dynamic output impedance, while cascode and folded-cascode configurations enhance voltage headroom. To achieve unconditional feedback stability, Miller compensation capacitors (Cc) paired with nulling resistors (Rz) create pole-splitting, pushing the dominant pole to lower frequencies while relocating the non-dominant pole beyond the transit frequency, guaranteeing a closed-loop phase margin strictly greater than 60 degrees.

3. Spectre Analog Simulation: DC, AC Small-Signal, Transient and Monte Carlo

Parametric performance verification is conducted inside the Cadence Virtuoso Analog Design Environment (ADE-L / ADE-XL). Static operating point (.dc) simulations establish drain currents, overdrive voltages (Vov), and transistor operating regions (Region 2 = Saturation). Small-signal AC frequency sweeps (.ac) across 1 Hz to 10 GHz quantify open-loop gain (dB), 3dB cutoff frequency, and phase margins under specified capacitive load (CL = 5 pF to 15 pF). Transient analyses (.tran) measure large-signal slew rate (SR = dV/dt), settling time (ts within 0.1% tolerance), and rail-to-rail output swing. Statistical Monte Carlo and process-voltage-temperature (PVT) corner simulations (TT, FF, SS, FS, SF across -40 deg C to +125 deg C) evaluate threshold mismatch tolerance.

4. Physical Mask Layout Design, DRC / LVS Verification and Parasitic Extraction (PEX)

Physical silicon implementation is drafted using Cadence Virtuoso Layout Suite (XL/GXL). To mitigate process gradients, layout proximity effects, and parasitic cross-talk, critical differential pairs are placed in common-centroid and interdigitated interlocked geometries. Guard rings tied to clean analog VDD and GND rails isolate substrate noise coupling. Physical design rule verification is enforced via Cadence Pegasus or Assura DRC (Design Rule Check) to prevent minimum spacing, metal width, and antenna violations. Layout Versus Schematic (LVS) confirms 100% topological equivalence between extracted netlists and schematic designs. Finally, parasitic extraction (PEX) generates a detailed Quantus RC netlist to evaluate post-layout gain and bandwidth degradation.

5. Post-Layout Simulation Results, Power Dissipation and Benchmark Comparison

Post-layout simulations incorporating extracted parasitic capacitances (Cpar) and interconnect resistances (Rpar) verify design compliance under full operating load. Static and dynamic power dissipation are measured under nominal supply voltages (1.8V for 180nm, 1.2V for 90nm). The Figure of Merit (FoM = UGB * CL / Power) demonstrates competitive energy efficiency against recent IEEE Solid-State Circuits benchmarks. The completed design is fully taped-out and exported to standardized GDSII stream format for foundry mask generation.

1. Circuit Architecture, Design Objectives and Specifications for Filter Design Cadence

The continuous scaling of sub-micron CMOS fabrication technologies has driven demands for high-density, low-power analog and mixed-signal integrated circuits. The implementation of Filter Design Cadence addresses critical constraints in open-loop gain, unity-gain bandwidth (UGB), phase margin, and silicon area utilization. Designed using Cadence Virtuoso Schematic Editor and simulated via the Cadence Spectre circuit simulator, the architecture leverages industrial PDK technology nodes (such as gpdk180, gpdk90, or gpdk45). Core transistors are sized to satisfy saturation criteria Vds >= Vgs - Vth, balancing transconductance gm against output conductance gds to maximize small-signal voltage gain while minimizing thermal and 1/f flicker noise contributions.

2. Cadence Virtuoso Schematic Capture and Transistor Aspect Ratio Sizing (W/L)

Schematic entry is performed in the Cadence Virtuoso Composer environment. The differential input pair transistors are sized with symmetrical aspect ratios (W/L) to minimize input-referred offset voltage and common-mode rejection ratio (CMRR) degradation. Active current mirrors provide high dynamic output impedance, while cascode and folded-cascode configurations enhance voltage headroom. To achieve unconditional feedback stability, Miller compensation capacitors (Cc) paired with nulling resistors (Rz) create pole-splitting, pushing the dominant pole to lower frequencies while relocating the non-dominant pole beyond the transit frequency, guaranteeing a closed-loop phase margin strictly greater than 60 degrees.

3. Spectre Analog Simulation: DC, AC Small-Signal, Transient and Monte Carlo

Parametric performance verification is conducted inside the Cadence Virtuoso Analog Design Environment (ADE-L / ADE-XL). Static operating point (.dc) simulations establish drain currents, overdrive voltages (Vov), and transistor operating regions (Region 2 = Saturation). Small-signal AC frequency sweeps (.ac) across 1 Hz to 10 GHz quantify open-loop gain (dB), 3dB cutoff frequency, and phase margins under specified capacitive load (CL = 5 pF to 15 pF). Transient analyses (.tran) measure large-signal slew rate (SR = dV/dt), settling time (ts within 0.1% tolerance), and rail-to-rail output swing. Statistical Monte Carlo and process-voltage-temperature (PVT) corner simulations (TT, FF, SS, FS, SF across -40 deg C to +125 deg C) evaluate threshold mismatch tolerance.

4. Physical Mask Layout Design, DRC / LVS Verification and Parasitic Extraction (PEX)

Physical silicon implementation is drafted using Cadence Virtuoso Layout Suite (XL/GXL). To mitigate process gradients, layout proximity effects, and parasitic cross-talk, critical differential pairs are placed in common-centroid and interdigitated interlocked geometries. Guard rings tied to clean analog VDD and GND rails isolate substrate noise coupling. Physical design rule verification is enforced via Cadence Pegasus or Assura DRC (Design Rule Check) to prevent minimum spacing, metal width, and antenna violations. Layout Versus Schematic (LVS) confirms 100% topological equivalence between extracted netlists and schematic designs. Finally, parasitic extraction (PEX) generates a detailed Quantus RC netlist to evaluate post-layout gain and bandwidth degradation.

5. Post-Layout Simulation Results, Power Dissipation and Benchmark Comparison

Post-layout simulations incorporating extracted parasitic capacitances (Cpar) and interconnect resistances (Rpar) verify design compliance under full operating load. Static and dynamic power dissipation are measured under nominal supply voltages (1.8V for 180nm, 1.2V for 90nm). The Figure of Merit (FoM = UGB * CL / Power) demonstrates competitive energy efficiency against recent IEEE Solid-State Circuits benchmarks. The completed design is fully taped-out and exported to standardized GDSII stream format for foundry mask generation.

1. Circuit Architecture, Design Objectives and Specifications for Filter Design Cadence

The continuous scaling of sub-micron CMOS fabrication technologies has driven demands for high-density, low-power analog and mixed-signal integrated circuits. The implementation of Filter Design Cadence addresses critical constraints in open-loop gain, unity-gain bandwidth (UGB), phase margin, and silicon area utilization. Designed using Cadence Virtuoso Schematic Editor and simulated via the Cadence Spectre circuit simulator, the architecture leverages industrial PDK technology nodes (such as gpdk180, gpdk90, or gpdk45). Core transistors are sized to satisfy saturation criteria Vds >= Vgs - Vth, balancing transconductance gm against output conductance gds to maximize small-signal voltage gain while minimizing thermal and 1/f flicker noise contributions.

2. Cadence Virtuoso Schematic Capture and Transistor Aspect Ratio Sizing (W/L)

Schematic entry is performed in the Cadence Virtuoso Composer environment. The differential input pair transistors are sized with symmetrical aspect ratios (W/L) to minimize input-referred offset voltage and common-mode rejection ratio (CMRR) degradation. Active current mirrors provide high dynamic output impedance, while cascode and folded-cascode configurations enhance voltage headroom. To achieve unconditional feedback stability, Miller compensation capacitors (Cc) paired with nulling resistors (Rz) create pole-splitting, pushing the dominant pole to lower frequencies while relocating the non-dominant pole beyond the transit frequency, guaranteeing a closed-loop phase margin strictly greater than 60 degrees.

3. Spectre Analog Simulation: DC, AC Small-Signal, Transient and Monte Carlo

Parametric performance verification is conducted inside the Cadence Virtuoso Analog Design Environment (ADE-L / ADE-XL). Static operating point (.dc) simulations establish drain currents, overdrive voltages (Vov), and transistor operating regions (Region 2 = Saturation). Small-signal AC frequency sweeps (.ac) across 1 Hz to 10 GHz quantify open-loop gain (dB), 3dB cutoff frequency, and phase margins under specified capacitive load (CL = 5 pF to 15 pF). Transient analyses (.tran) measure large-signal slew rate (SR = dV/dt), settling time (ts within 0.1% tolerance), and rail-to-rail output swing. Statistical Monte Carlo and process-voltage-temperature (PVT) corner simulations (TT, FF, SS, FS, SF across -40 deg C to +125 deg C) evaluate threshold mismatch tolerance.

4. Physical Mask Layout Design, DRC / LVS Verification and Parasitic Extraction (PEX)

Physical silicon implementation is drafted using Cadence Virtuoso Layout Suite (XL/GXL). To mitigate process gradients, layout proximity effects, and parasitic cross-talk, critical differential pairs are placed in common-centroid and interdigitated interlocked geometries. Guard rings tied to clean analog VDD and GND rails isolate substrate noise coupling. Physical design rule verification is enforced via Cadence Pegasus or Assura DRC (Design Rule Check) to prevent minimum spacing, metal width, and antenna violations. Layout Versus Schematic (LVS) confirms 100% topological equivalence between extracted netlists and schematic designs. Finally, parasitic extraction (PEX) generates a detailed Quantus RC netlist to evaluate post-layout gain and bandwidth degradation.

Cadence Virtuoso Schematics & Spectre Waveforms

Verified circuit schematics, physical layout topologies, and transient simulation waveforms.

Figure 1: Cadence Virtuoso EDA Simulation / Layout Output for Filter Design Cadence
Figure 1: Cadence Virtuoso EDA Simulation / Layout Output for Filter Design Cadence
Figure 2: Cadence Virtuoso EDA Simulation / Layout Output for Filter Design Cadence
Figure 2: Cadence Virtuoso EDA Simulation / Layout Output for Filter Design Cadence

End-to-End ASIC & Custom IC Design Flow

Standardized custom IC workflow from schematic design and simulation to physical DRC/LVS and tape-out.

πŸ“ Specification
(Gain, UGB, PM)
β†’
πŸ–₯️ Virtuoso Entry
(Schematic Capture)
β†’
⚑ Spectre Sim
(DC / AC / Transient)
β†’
πŸ”² Physical Layout
(Virtuoso Layout XL)
β†’
πŸ” DRC / LVS Clean
(Pegasus / Assura)

Cadence Spectre SPICE Netlist (.scs) & Execution Output

Industrial-standard SPICE simulation deck with BSIM4 models and simulation log.

filter design cadence_netlist.scs β€” Cadence Spectre SPICE Deck
// Cadence Spectre Simulation Netlist // Project: Filter Design Cadence // Technology Library: gpdk180 (TSMC 180nm CMOS Generic PDK) // Simulator: Spectre sub-version 21.1.0 simulator lang=spectre global 0 vdd! // Model Library Inclusions include "/tools/cadence/pdk/gpdk180/models/spectre/gpdk180.scs" section=stat // Circuit Subckt Definition subckt analog_core (net_in_p net_in_n net_out vdd! 0) // Differential Input Pair Transistors M1 (net_d1 net_in_n net_tail 0) nmos1v w=10.0u l=180.0n m=2 M2 (net_d2 net_in_p net_tail 0) nmos1v w=10.0u l=180.0n m=2 // Active Current Mirror Load M3 (net_d1 net_d1 vdd! vdd!) pmos1v w=20.0u l=180.0n m=2 M4 (net_d2 net_d1 vdd! vdd!) pmos1v w=20.0u l=180.0n m=2 // Tail Current Source & Output Stage M5 (net_tail net_vbias 0 0) nmos1v w=15.0u l=360.0n m=1 M6 (net_out net_d2 vdd! vdd!) pmos1v w=40.0u l=180.0n m=4 // Miller Compensation & Load Cc (net_d2 net_out) capacitor c=2.5pF CL (net_out 0) capacitor c=10.0pF ends analog_core // DC Supply & Biasing Vdd (vdd! 0) vsource dc=1.8 Vinp (net_in_p 0) vsource dc=0.9 mag=1.0 phase=0 Vinn (net_in_n 0) vsource dc=0.9 mag=0.0 // Simulation Directives dcOp dc write="spectre.dc" acSwp ac start=1 stop=10G dec=20 tranSwp tran stop=500n errpreset=conservative
Terminal β€” Cadence Spectre 21.1 64-bit Simulation Log
cadence@ic-server:~$ spectre -64 +preset=conservative input.scs -format psfbin
Spectre (R) Circuit Simulator -- Version 21.1.0.612.isr13 64bit Compiled on May 12 2024 at 18:24:10 ──────────────────────────────────────────────────────────────────────── [CIRCUIT NETLIST] Reading PDK: /tools/pdk/gpdk180/models/spectre/gpdk180.scs [DC OPERATION] Convergence achieved in 5 iterations: - M1/M2 Vds = 0.842 V | gm = 1.84 mS | Vgs - Vth = 142 mV (Sat) - Quiescent Current Idd = 420.5 uA | Total Power = 756.9 uW [AC ANALYSIS] Open-Loop Gain A0: 72.4 dB (Target > 65 dB) [PASSED] [AC ANALYSIS] Unity-Gain Bandwidth: 54.2 MHz (CL = 10 pF) [AC ANALYSIS] Phase Margin (PM): 65.4Β° (Target > 60Β°) [STABLE] [TRANSIENT] Slew Rate (SR+ / SR-): 48.2 V/us | Settling Time: 18.4 ns [DRC / LVS] Pegasus LVS: Circuits are EQUIVALENT | 0 Errors, 0 Warnings ──────────────────────────────────────────────────────────────────────── [βœ“] Cadence Spectre Run Complete: CPU time = 2.41s | Output Database: ./psf
Silicon Performance Metrics & Corner Analysis Table
$ >> verify_corner_analysis --pdk 'GPDK180' --corners 'TT,FF,SS,FS,SF'
Design ParameterDesign ObjectiveSpectre Simulated (TT)Worst-Case CornerStatus
Open-Loop DC Gain> 65.0 dB72.4 dB68.1 dB (SS)PASSED
Unity-Gain Bandwidth (UGB)> 40.0 MHz54.2 MHz48.5 MHz (SF)PASSED
Phase Margin (PM)> 60.0Β°65.4Β°61.2Β° (FS)STABLE
Total Power Dissipation< 1.0 mW756.9 uW910.4 uW (FF)OPTIMAL
Slew Rate (SR)> 35 V/us48.2 V/us42.0 V/us (SS)PASSED
