Folded Cascode Amplifier Overview This repository contains the schematic design, testbench setup, and simulation results for a Folded Cascode Amplifier. The primary objective of this design was to achieve a targeted Unity Gain Bandwidth (UGB) of 10 MHz while ensuring robust stability and high open-loop gain. Key architectural choices include the implementation of a cascode current mirror for precise biasing and enhanced output resistance. To ensure optimal performance, the transistor sizing was rigorously optimized, and all MOSFETs were verified to be operating strictly in the saturation region using overdrive voltage analysis. Specifications & Performance Metrics The circuit was designed and simulated using Cadence Virtuoso. The final design successfully met and exceeded all targeted parameters, including bandwidth, gain, and stability margins. Parameter Target Achieved Unity Gain Bandwidth (UGB) 10 MHz 12.88 MHz Open-Loop AC Gain > 60 dB 61.89 dB Phase Margin > 60ยฐ 85.1ยฐ Testbench Configuration The amplifier's AC response was characterized using a DC-closed loop and AC-open loop testbench configuration. The specific operating conditions applied in the testbench are: Supply Voltage ( $V_{DD}$ ): 5 V Input Common-Mode Voltage: 2.5 V Capacitive Load ( $C_L$ ): 1 pF Schematics and Simulation Results 1. Circuit Schematic 2. Characterization Testbench The testbench utilizes a 5V supply with a 2.5V common-mode input and a 1 pF load capacitor. 3. AC Response (Bode Plot) The AC response plot demonstrates a DC gain of 61.89 dB and a UGB of 12.88 MHz with a phase margin of 85.1ยฐ. Tools Used EDA Tool: Cadence Virtuoso Analyses Performed: DC Operating Point, AC Analysis

This repository contains the schematic design, testbench setup, and simulation results for a Folded Cascode Amplifier. The primary objective of this design was to achieve a targeted Unity Gain Bandwidth (UGB) of 10 MHz while ensuring robust stability and high open-loop gain.

Key architectural choices include the implementation of a cascode current mirror for precise biasing and enhanced output resistance. To ensure optimal performance, the transistor sizing was rigorously optimized, and all MOSFETs were verified to be operating strictly in the saturation region using overdrive voltage analysis.

The circuit was designed and simulated using Cadence Virtuoso. The final design successfully met and exceeded all targeted parameters, including bandwidth, gain, and stability margins.

The amplifier's AC response was characterized using a DC-closed loop and AC-open loop testbench configuration. The specific operating conditions applied in the testbench are:

The testbench utilizes a 5V supply with a 2.5V common-mode input and a 1 pF load capacitor.

The AC response plot demonstrates a DC gain of 61.89 dB and a UGB of 12.88 MHz with a phase margin of 85.1ยฐ.

This repository contains the design and simulation of a single-ended Folded Cascode Operational Transconductance Amplifier (OTA) . The circuit was designed and characterized using **Cadence Virtuoso**. The primary objective of this project was to achieve Unity Gain Bandwidth (UGB) of 10 MHz while maintaining stability and a high open-loop gain.

Folded-Cascode CMOS Operational Amplifier Overview This project presents the design and simulation of a folded-cascode CMOS operational amplifier using Cadence Virtuoso and GPDK 180 nm technology. The folded-cascode architecture uses a folded structure to route current from the input differential pair to the cascode load. This architecture provides high voltage gain and improved output swing compared with a telescopic architecture, while remaining suitable for low-voltage and high-speed applications. Objectives Design a folded-cascode CMOS operational amplifier. Analyze the frequency response and dynamic performance. Evaluate gain, CMRR, slew rate, UGB, THD, phase margin, bandwidth, power consumption, and noise. Study the effect of device mismatch using Monte Carlo analysis. Evaluate circuit robustness using PVT analysis. Analyze the major noise sources in the circuit. Tools and Technology Parameter Details EDA Tool Cadence Virtuoso Technology GPDK 180 nm Circuit Folded-Cascode CMOS Op-Amp Architecture Single-stage folded-cascode Analyses AC, Noise, Monte Carlo, PVT Circuit Architecture The folded-cascode amplifier uses a folded structure to transfer current from the input differential pair to the cascode load. Compared with a telescopic architecture, the folded structure provides improved output swing while maintaining high gain. The architecture requires careful biasing to ensure that all MOSFETs remain in the saturation region during operation. Key Features High voltage gain Improved output swing compared with telescopic architecture Low-power operation High-speed operation Suitable for low-voltage analog applications Requires multiple bias voltages and careful biasing Schematic AC Analysis AC analysis was performed to characterize the small-signal frequency response of the folded-cascode amplifier. The analysis evaluates voltage gain, CMRR, slew rate, unity-gain bandwidth, THD, phase margin, bandwidth, power consumption, and noise. Nominal AC Performance Parameter Result Gain 89.36 dB CMRR 114.168 dB Slew Rate 4.79 MV/s Unity-Gain Bandwidth 9.766 MHz THD 0.366% Phase Margin 81.20ยฐ Power Consumption 12.89 ยตW Bandwidth 332.615 Hz Noise 5.27 ร— 10โปยนโท V/โˆšHz Monte Carlo Analysis Monte Carlo analysis was performed to evaluate the effect of statistical device mismatch on the performance of the folded-cascode amplifier. The simulation results showed stable frequency response and low-power operation with variations in the circuit parameters. Monte Carlo Mean Results Parameter Mean Value Unity-Gain Bandwidth 8.65 MHz Power Consumption 33.7 ยตW Slew Rate 48.1 MV/s Phase Margin 87.1ยฐ CMRR 56.8 dB The phase margin remained high, indicating good stability across the simulated mismatch conditions. Noise Analysis Noise analysis was performed to identify the dominant noise mechanisms in the folded-cascode architecture. The major noise sources include: Input differential pair Current mirrors Bias branches Noise Behavior At low frequencies, flicker noise (1/f noise) is the dominant noise mechanism. At higher frequencies, thermal noise becomes the dominant contributor. The folded-cascode architecture contains more noise paths than a telescopic amplifier because of its folded signal path and additional biasing branches. PVT Analysis PVT analysis was performed to evaluate circuit behavior under process, voltage, and temperature variations. The analysis provides insight into the robustness of the folded-cascode amplifier under different operating conditions. PVT Observations Parameter Observed Value Power Consumption ~33.7 ยตW Slew Rate ~47.9 MV/s Bandwidth ~336 kHz CMRR ~85 dB Performance Summary Nominal Performance Parameter Result Gain 89.36 dB CMRR 114.168 dB UGB 9.766 MHz Slew Rate 4.79 MV/s THD 0.366% Phase Margin 81.20ยฐ Power 12.89 ยตW Bandwidth 332.615 Hz Robustness Analysis The Monte Carlo and PVT simulations were used to evaluate the effect of mismatch and operating-condition variations. The results demonstrate: High phase margin Low-power operation Stable unity-gain bandwidth Good common-mode rejection Fast slew response Key Design Trade-offs Parameter Folded-Cascode Architecture Gain High Output Swing Better than telescopic Power Low Speed High Noise Multiple noise paths Biasing More complex Main Advantage High gain with improved output swing Main Limitation Increased circuit complexity and noise paths Key Design Concepts This project provided practical experience with: Folded-cascode amplifier architecture CMOS differential pair design Cascode structures Current mirrors Bias voltage generation High-output-impedance design Gain enhancement through cascoding Frequency-response analysis Noise analysis Monte Carlo mismatch analysis PVT analysis Phase-margin and stability evaluation Low-power analog circuit design Conclusion A folded-cascode CMOS operational amplifier was designed and simulated using Cadence Virtuoso with GPDK 180 nm technology . The design achieved a nominal voltage gain of 89.36 dB , unity-gain bandwidth of 9.766 MHz , phase margin of 81.20ยฐ , and power consumption of 12.89 ยตW . Monte Carlo and PVT analyses were performed to study circuit robustness under mismatch and operating-condition variations. Noise analysis showed that flicker noise dominates at low frequencies while thermal noise becomes dominant at higher frequencies. The project demonstrates the practical trade-offs between gain, output swing, speed, power consumption, noise, and biasing complexity in folded-cascode analog amplifier design.

1. Circuit Architecture, Design Objectives and Specifications for Folded Cascode Opamp Cadence

The continuous scaling of sub-micron CMOS fabrication technologies has driven demands for high-density, low-power analog and mixed-signal integrated circuits. The implementation of Folded Cascode Opamp Cadence addresses critical constraints in open-loop gain, unity-gain bandwidth (UGB), phase margin, and silicon area utilization. Designed using Cadence Virtuoso Schematic Editor and simulated via the Cadence Spectre circuit simulator, the architecture leverages industrial PDK technology nodes (such as gpdk180, gpdk90, or gpdk45). Core transistors are sized to satisfy saturation criteria Vds >= Vgs - Vth, balancing transconductance gm against output conductance gds to maximize small-signal voltage gain while minimizing thermal and 1/f flicker noise contributions.

2. Cadence Virtuoso Schematic Capture and Transistor Aspect Ratio Sizing (W/L)

Schematic entry is performed in the Cadence Virtuoso Composer environment. The differential input pair transistors are sized with symmetrical aspect ratios (W/L) to minimize input-referred offset voltage and common-mode rejection ratio (CMRR) degradation. Active current mirrors provide high dynamic output impedance, while cascode and folded-cascode configurations enhance voltage headroom. To achieve unconditional feedback stability, Miller compensation capacitors (Cc) paired with nulling resistors (Rz) create pole-splitting, pushing the dominant pole to lower frequencies while relocating the non-dominant pole beyond the transit frequency, guaranteeing a closed-loop phase margin strictly greater than 60 degrees.

3. Spectre Analog Simulation: DC, AC Small-Signal, Transient and Monte Carlo

Parametric performance verification is conducted inside the Cadence Virtuoso Analog Design Environment (ADE-L / ADE-XL). Static operating point (.dc) simulations establish drain currents, overdrive voltages (Vov), and transistor operating regions (Region 2 = Saturation). Small-signal AC frequency sweeps (.ac) across 1 Hz to 10 GHz quantify open-loop gain (dB), 3dB cutoff frequency, and phase margins under specified capacitive load (CL = 5 pF to 15 pF). Transient analyses (.tran) measure large-signal slew rate (SR = dV/dt), settling time (ts within 0.1% tolerance), and rail-to-rail output swing. Statistical Monte Carlo and process-voltage-temperature (PVT) corner simulations (TT, FF, SS, FS, SF across -40 deg C to +125 deg C) evaluate threshold mismatch tolerance.

4. Physical Mask Layout Design, DRC / LVS Verification and Parasitic Extraction (PEX)

Physical silicon implementation is drafted using Cadence Virtuoso Layout Suite (XL/GXL). To mitigate process gradients, layout proximity effects, and parasitic cross-talk, critical differential pairs are placed in common-centroid and interdigitated interlocked geometries. Guard rings tied to clean analog VDD and GND rails isolate substrate noise coupling. Physical design rule verification is enforced via Cadence Pegasus or Assura DRC (Design Rule Check) to prevent minimum spacing, metal width, and antenna violations. Layout Versus Schematic (LVS) confirms 100% topological equivalence between extracted netlists and schematic designs. Finally, parasitic extraction (PEX) generates a detailed Quantus RC netlist to evaluate post-layout gain and bandwidth degradation.

5. Post-Layout Simulation Results, Power Dissipation and Benchmark Comparison

Post-layout simulations incorporating extracted parasitic capacitances (Cpar) and interconnect resistances (Rpar) verify design compliance under full operating load. Static and dynamic power dissipation are measured under nominal supply voltages (1.8V for 180nm, 1.2V for 90nm). The Figure of Merit (FoM = UGB * CL / Power) demonstrates competitive energy efficiency against recent IEEE Solid-State Circuits benchmarks. The completed design is fully taped-out and exported to standardized GDSII stream format for foundry mask generation.
