CMOS Inverter Design and GDSII Generation using Cadence Virtuoso (GPDK90) This repository documents the design and analysis of a CMOS inverter using Cadence Virtuoso with GPDK90 technology . The project covers the entire workflow from schematic design to GDSII generation, including pre-layout and post-layout simulations, delay calculations, RC parasitics extraction, and validation through DRC and LVS checks. The goal was to successfully implement the CMOS inverter design and perform a detailed comparison between pre-layout and post-layout simulation results. Tools & Technologies Cadence Virtuoso GPDK90 technology Project Workflow Schematic Design : Created the schematic for the CMOS inverter and generated its symbol for further use. Testbench Setup : Designed a testbench for simulating the inverter's behavior. Analysis Setup : Configured the Analog Design Environment (ADE) for transient and DC sweep analyses. Simulation Results : Performed transient and DC sweep analyses to obtain the Voltage Transfer Characteristics (VTC) and threshold voltage . Layout Design : Completed the physical layout of the CMOS inverter, ensuring design integrity. DRC & LVS Checks : Successfully cleared Design Rule Check (DRC) and Layout Versus Schematic (LVS) checks. RC Parasitics Extraction : Extracted the parasitics from the layout to understand the impact on performance. Pre-Layout and Post-Layout Simulations : Performed simulations to compare performance before and after layout. Pre-Layout Results : Delay: 115.1 ps Post-Layout Results : Delay: 122.4 ps GDSII File Generation : Exported the final GDSII file for tapeout. Conclusion This project successfully completed the design, simulation, and layout of a CMOS inverter using Cadence Virtuoso. The pre-layout and post-layout results were compared, revealing a slight increase in delay post-layout, as expected due to parasitics. The final GDSII file is ready for fabrication. License This project is licensed under the MIT License.
This repository documents the design and analysis of a CMOS inverter using Cadence Virtuoso with GPDK90 technology . The project covers the entire workflow from schematic design to GDSII generation, including pre-layout and post-layout simulations, delay calculations, RC parasitics extraction, and validation through DRC and LVS checks.
The goal was to successfully implement the CMOS inverter design and perform a detailed comparison between pre-layout and post-layout simulation results.
Schematic Design : Created the schematic for the CMOS inverter and generated its symbol for further use.
Analysis Setup : Configured the Analog Design Environment (ADE) for transient and DC sweep analyses.
Simulation Results : Performed transient and DC sweep analyses to obtain the Voltage Transfer Characteristics (VTC) and threshold voltage .
Layout Design : Completed the physical layout of the CMOS inverter, ensuring design integrity.
DRC & LVS Checks : Successfully cleared Design Rule Check (DRC) and Layout Versus Schematic (LVS) checks.
RC Parasitics Extraction : Extracted the parasitics from the layout to understand the impact on performance.
Pre-Layout and Post-Layout Simulations : Performed simulations to compare performance before and after layout.
This project successfully completed the design, simulation, and layout of a CMOS inverter using Cadence Virtuoso. The pre-layout and post-layout results were compared, revealing a slight increase in delay post-layout, as expected due to parasitics. The final GDSII file is ready for fabrication.
About This repository contains the design and analysis of a CMOS inverter using Cadence Virtuoso with GPDK90 technology. The project includes schematic and layout design, pre-layout and post-layout simulations, delay calculations, RC parasitics extraction, and final GDSII file generation.
CMOS Inverter Design and GDSII Generation using Cadence Virtuoso (GPDK90) This repository documents the design and analysis of a CMOS inverter using Cadence Virtuoso with GPDK90 technology . The project covers the entire workflow from schematic design to GDSII generation, including pre-layout and post-layout simulations, delay calculations, RC parasitics extraction, and validation through DRC and LVS checks. The goal was to successfully implement the CMOS inverter design and perform a detailed comparison between pre-layout and post-layout simulation results. Tools & Technologies Cadence Virtuoso GPDK90 technology Project Workflow Schematic Design : Created the schematic for the CMOS inverter and generated its symbol for further use. Testbench Setup : Designed a testbench for simulating the inverter's behavior. Analysis Setup : Configured the Analog Design Environment (ADE) for transient and DC sweep analyses. Simulation Results : Performed transient and DC sweep analyses to obtain the Voltage Transfer Characteristics (VTC) and threshold voltage . Layout Design : Completed the physical layout of the CMOS inverter, ensuring design integrity. DRC & LVS Checks : Successfully cleared Design Rule Check (DRC) and Layout Versus Schematic (LVS) checks. RC Parasitics Extraction : Extracted the parasitics from the layout to understand the impact on performance. Pre-Layout and Post-Layout Simulations : Performed simulations to compare performance before and after layout. Pre-Layout Results : Delay: 115.1 ps Post-Layout Results : Delay: 122.4 ps GDSII File Generation : Exported the final GDSII file for tapeout. Conclusion This project successfully completed the design, simulation, and layout of a CMOS inverter using Cadence Virtuoso. The pre-layout and post-layout results were compared, revealing a slight increase in delay post-layout, as expected due to parasitics. The final GDSII file is ready for fabrication. License This project is licensed under the MIT License.
