Bolted Joint Composite Ansys: Civil & Structural Engineering Comprehensive Investigation Integrated Analysis: ETABS · STAAD.Pro · GIS/QGIS · ABAQUS FEA · MATLAB · IoT Sensors · ~6220 Words Chapter 1: Structural Engineering Modeling & Problem Statement Bolted assemblies can significantly increase simulation complexity and solve times. This article explores practical approaches for simplifying bolt models while maintaining accuracy, including contact regions, pressure cones, beam connections, and bolt pretension techniques.
Analytical & Numerical Modeling Methodology
It can take many years of experience of both product knowledge and simulation techniques to understand where to compromise the simulation model to enable it to be solved in the computational resource available while maintaining a reasonable level of accuracy. Working with bolted assemblies is one area where this trade off is very apparent. Do you model the whole bolt, with washers and nuts, possible even the thread? Or do you use some level of abstraction, some representation of the bolt, which captures the behaviour of the bolted connection, but allows a much more efficient solution? We discuss some of the possible approaches below.
Finite Element Results & Code Compliance
Many engineering structures are assemblies that are held together using bolted connections and it is quite normal for design engineers to build CAD models that contain many nut, bolt and washer sub-assemblies within a wider full assembly model. When we try to mesh such assemblies, we can often end up with very high element counts, resulting in many system equations and therefore excessive run times. Indeed, in such circumstances it is not unusual to produce a meshed model that is too large to be able to be handled, in a reasonable amount of time, by the computational resources available. Compromises must be made.
