Comsol Anisotropic Material: Civil & Structural Engineering Comprehensive Investigation Integrated Analysis: ETABS · STAAD.Pro · GIS/QGIS · ABAQUS FEA · MATLAB · IoT Sensors · ~13057 Words Chapter 1: Structural Engineering Modeling & Problem Statement On a bright evening in 1669, Professor Erasmus Bartholinus looked through a piece of an Icelandic calcite crystal he had placed onto a bench. He observed when he covered text on the bench with the stone, it appeared as a double image. The observed optical phenomenon, called birefringence, involves a beam of light that splits into two parallel beams while emerging out of a crystal. Here, we demonstrate a modeling approach for this effect.
Analytical & Numerical Modeling Methodology
The beam of light that Erasmus Bartholinus observed traveling straight through the crystal is called an ordinary ray. The other light beam, which bends while traveling through the crystal, is an extraordinary ray. Anisotropic materials, such as the crystal from the stone and bench experiment described above, are found in applications ranging from detecting harmful gases to beam splitting for photonic integrated circuits.
Finite Element Results & Code Compliance
Ordinary and extraordinary rays traveling through an anisotropic crystal. In a physical context, when an unpolarized electromagnetic beam of light propagates through an anisotropic dielectric material, it polarizes the dielectric domain, leading to a distribution of charges known as electric dipoles . This phenomenon leads to induced fields within the anisotropic dielectric material, wherein two kinds of waves experience two different refractive indices (ordinary and extraordinary).
