Eee Projects On Burglar Alarm Circuit Using Laser And Ldr: Power Electronics, MATLAB/Simulink & Circuit Modeling Integrated Analysis: MATLAB/Simulink · MOSFET/IGBT Gate Drivers · SPWM/SVPWM · THD Spectrum · ~4532 Words Chapter 1: Power Electronics Overview, System Specifications & Topology Modeling We need safety and security for our valuable things, to protect our property simple and robust security alarm circuit designed by using easily available components. We know the LASER ( Light Amplification by Stimulated Emission of Radiation) light has high strength focused light rays, in this project we have used that laser light as a fence.
Analytical & State-Space Control Methodology
Laser security alarm circuit produce highly audible buzzer beep sound when the laser light blocked. Here LDR placed to sense the laser light from the laser diode . Two NPN (BC548) transistors implemented in this security alarm circuit as a switching device. LDR (Light Dependent Resistor) connected to the base terminal of Q2 transistor through R4 resistor this LDR gives low resistance when the laser light falls on it and gives high resistance when there is no laser light due to that supply voltage to the Q2 transistor varies depends on the LDR resistance.
Simulink Waveforms & Power Quality Findings
Figure 1: Power Converter Circuit Schematic & Electrical Interfacing for Eee Projects On Burglar Alarm Circuit Using Laser And Ldr The Q1 transistor collector terminal is connected with buzzer and Indicator LED and then base terminal of Q1 transistor connected to the Q2 transistor collector terminal. Each transistor needs some threshold voltage to get turn ON, If the laser light falls on LDR it allows supply to the Q2 base hence it becomes turn ON so the Q1 transistor base don’t get any bias, due to that Q1 transistor stays in OFF condition so the buzzer and LED also in OFF condition.
