Eee Projects On Metal Detector Circuit Using Beat Frequency Oscillator: Power Electronics, MATLAB/Simulink & Circuit Modeling Integrated Analysis: MATLAB/Simulink · MOSFET/IGBT Gate Drivers · SPWM/SVPWM · THD Spectrum · ~4522 Words Chapter 1: Power Electronics Overview, System Specifications & Topology Modeling Build a single-coil LC oscillator Arduino metal detector. Includes Colpitts circuit specs, coil winding data, complete C++ code, and I2C debugging.
Analytical & State-Space Control Methodology
An Arduino metal detector built on the Beat Frequency Oscillator (BFO) or single-coil LC resonance principle relies on a deceptively simple physical interaction: when a metallic object enters the magnetic field of a search coil, eddy currents induced in the metal alter the coil's inductance. This shifts the resonant frequency of the oscillator circuit. By measuring this microsecond-level frequency shift with a microcontroller, you can detect coins, nails, or foil buried in dry soil or hidden behind drywall.
Simulink Waveforms & Power Quality Findings
Many hobbyist guides incorrectly attempt to use a 555 timer in a standard astable configuration with an inductor. A standard 555 astable relies on RC (resistor-capacitor) timing; forcing an inductor into that topology results in erratic triggering and flyback voltage spikes that can destroy the IC. The correct, robust approach is a Colpitts LC oscillator built with a single NPN transistor, feeding a clean square wave into the Arduino's digital interrupt or pulseIn pin.
