Abstract. Institutional canteens in schools and offices still often rely on cash or token payments, which create long queues, calculation errors, and limited transparency. An IoT-integrated RFID system for smart canteen payment management automates billing and monitoring by giving each user a contactless RFID smart card. When the card is tapped at the counter, the RFID reader identifies the user and an IoT module (typically ESP32) links the terminal to a cloud server. The server stores food selections and spending data, applies predefined prices, and deducts the amount from the user’s prepaid balance or points. Administrators can view transactions, balances, and sales online in real time for better decisions and inventory planning. The approach shortens waiting times, reduces cash handling, cuts manual arithmetic errors, and supports consumption analysis. Keywords for such projects include RFID, smart card, ESP32 microcontroller, fare optimization, cashless payment, canteen management, and real-time monitoring—making this an excellent final-year IoT topic for BE, BTech, and MTech students.

1. Introduction. Digital payment growth has changed how institutions handle high volumes of daily canteen transactions for students and staff. Conventional cash or manual token systems cause long queues, calculation mistakes, and inefficient service, which hurt user experience and increase administrative load. Automated, secure, contactless solutions are therefore needed. RFID-based smart cards provide fast identification by tapping a card, which speeds up billing and improves convenience. A smart card-based canteen fare optimization system using RFID aims to streamline billing, ensure accurate fare deduction, reduce manual intervention, and enable centralized data collection for real-time monitoring, consumption analysis, and better inventory management. Adoption of RFID-based fare optimization modernizes campus canteen management and offers a scalable, cost-effective path toward smart campus infrastructure.

1.1 Motivation. Cash-based and manual billing are time-consuming, error-prone, and weak on transaction traceability. As daily volume grows, these limits hurt scalability and satisfaction. RFID smart cards enable rapid identification, automated fare calculation, and real-time processing with minimal human intervention. Centralized data collection supports monitoring, consumption analysis, and inventory optimization for informed decisions. The goal is a scalable, cost-effective, user-centric canteen fare system that strengthens institutional service delivery.

1.2 Objectives. Typical project objectives are: automate canteen billing with RFID contactless cards; ensure accurate, secure fare calculation with real-time balance deduction; reduce transaction time and manual intervention; keep centralized records for monitoring and analysis; analyze consumption patterns for inventory planning; improve user convenience and service quality; and deliver a scalable solution suitable for smart campus environments.

2. Literature Context. Prior work includes RFID canteen automation that sped up transactions but lacked advanced cloud monitoring and online recharge; cashless cafeteria systems that improved convenience but needed fuller balance and recharge support; IoT smart canteen systems with cloud storage and real-time monitoring that increased internet dependency; prepaid smart cards without strong real-time logging or digital recharge; and web-based RFID payment systems that cut queues but lacked modern UPI-style recharge. An integrated design that combines RFID payment, cloud database management, real-time logging, and digital recharge remains a clear gap that student projects can address.

3. Methodology and Architecture of the Device. The system uses RFID cards as payment identifiers. Billing may be entered by canteen staff while user accounts live in a centralized cloud database. A tap-to-pay model without PIN relies on backend validation of card ownership before authorization. Monetary value is often represented as points: UPI recharges via web or mobile app convert to points and update the database automatically. After each transaction, users receive a notification with payment details and remaining balance.

3.1 System architecture. When the user taps the RFID card, the reader captures the unique card ID and sends it to the microcontroller (ESP32). The controller verifies user details with the server database over the IoT network. After authentication, the billing module calculates the amount and deducts it from the prepaid balance. Transaction details are stored in the cloud and a notification is sent. If balance is low, the transaction is denied and the user is prompted to recharge.

3.2 Detailed workflow. (1) Card detection: unique ID is read; no personal or financial data is stored on the card. (2) Ownership verification: ID is checked against the cloud database; invalid or blocked cards are rejected. (3) Manual item entry or scanning: items map to predefined prices; total fare is computed. (4) Balance check: fare is compared to available points; insufficient balance declines the payment. (5) Point deduction and logging: approved amount is deducted; card ID, amount, timestamp, and remaining balance are stored. (6) User notification: SMS or app message reports success or failure. (7) Online recharge: web/mobile app shows UPI QR; payment confirmation credits points automatically. (8) Retry after recharge: updated balance is verified on the next tap.

3.3 Hardware and software. Typical hardware: ESP32 microcontroller, RC522 RFID reader, RFID smart cards, matrix keypad (optional amount entry), display or computer terminal, stable Wi-Fi, 5 V regulated supply, and user smartphone. Software stack: Arduino IDE for firmware, MFRC522 library for the reader, Firebase (or similar) Arduino library for cloud connectivity, web and mobile apps for recharge and balance view, cloud database for users/balances/transactions, UPI QR interface, and browser dashboards for admin and users.

4. Implementation Highlights. Users are registered with personal details, mobile number, and assigned card ID; accounts start with a point balance; food prices are predefined. Each card stores only a unique ID; sensitive data stays in the cloud, which simplifies replacement of lost cards. Authentication is backend ownership validation without PIN. Billing is staff-driven; the card is used only for payment authorization. After fare calculation, balance is verified, points are deducted if sufficient, and records are logged. UPI recharge updates the cloud instantly. All payments and recharges are timestamped for admin monitoring and reports.

5. Results and Discussion. Under real canteen usage, the system performed contactless transactions with backend ownership verification, accurate staff billing, and payment only after sufficient balance checks. Point-based balances supported secure internal accounting. Online UPI recharge updated balances without manual steps. Users received notifications of deducted amount and remaining balance; insufficient-balance cases were declined with alerts. Overall outcomes include reduced transaction time, fewer billing errors, higher transparency, and suitability for institutional deployment. Hardware benches typically show RFID reader, keypad, LCD, and microcontroller wiring; admin tools show recharge forms and Firebase (or equivalent) realtime database trees reflecting live balances and history.

6. Advantages. Contactless speed and hygiene; less cash handling; automated fare deduction; real-time cloud visibility for admins; consumption analytics for inventory; UPI-based self-recharge; blocked-card protection; scalable from a single counter to multi-outlet campuses; and a clear student learning path covering RFID, ESP32, MQTT/HTTP cloud links, Firebase or similar backends, and mobile/web UX.

7. Conclusion. Cash and partial-digital canteen systems still produce queues, errors, and weak transparency. An IoT-integrated RFID smart canteen payment system separates manual billing from automated payment authorization, verifies card ownership in the cloud, uses point-based balances, supports UPI recharge, and logs every transaction with user notifications. Experimental use shows shorter transaction times, fewer errors, and a reliable, user-friendly platform for institutional canteens. For students, Canteen Automation IoT is a complete capstone: RFID sensing, ESP32 firmware, cloud databases, dashboards, security-minded design, and viva-ready documentation for careers in campus IoT, retail automation, and embedded systems.
