Numerical modeling for heatsink emissions in power electronics J. Kulanayagam1, J. H. Hagmann1, S. Schenke1, K. F. Hoffmann2, and S. Dickmann1 1Institute for Fundamentals of Electrical Engineering, Germany Abstract. The parasitic coupling between power semicon- ductors and the heat sink is responsible for noise current in Switching Mode Power Supply (SMPS) systems.

Figure: System Model & Simulation Flow for Heatsink Design Power Electronics

In

this paper, the variations in the radiation characteristics of heatsinks are investigated with respect to their geometries by use of numerical models. Analyses are facilitated by using a mopole antenna as an EMI receiver and by using simplified heatsink models as EMI transmitters to model the heatsink radiated emissions. In addition, the analysis is confirmed us- ing laboratory measurements.

Figure: System Model & Simulation Flow for Heatsink Design Power Electronics

Introduction

Power-switching semiconductors (MOSFET’s/IGBT’s) are usually mounted on heat sinks to keep the temperature below an acceptable limit. Parasitic capacitances can be created be- tween the switching devices and the heatsink. The electric isolator (mica) acts as a dielectric of these capacitances. The result of this parasitic effects, the common-mode EMI is gen- erated in Switching Mode Power Supply circuits (Tihanyi, 1995). If this current contains a high number of harmonic components and its flows through the heatsink, the heatsink becomes an antenna. However, the maximum radiation oc- curs at different frequencies depending on the heatsink ge- ometry (Brench, 1994; Das and Roy, 1998). In consequence, this current could violate the EMC standards due to radiation.

Figure: System Model & Simulation Flow for Heatsink Design Power Electronics

Therefore the heat sink should be well designed. A typical heatsink configuration is shown in Fig. 1. In this paper, the variations in the radiation characteristics of non-grounded and grounded heatsinks are investigated. A previous paper have shown that very little difference in the general electromagnetic behaviors of a finned heatsink and a heatsink as a solid block (Dawson et al., 2001). In con- sequence, a heatsink as a solid block allows a much simpler simulation model.

Fr-4

Fig. 1. Schematic representation of parasitic capacitance.

Experimental Setup

In order to represent a ground plane, a rectangular piece of aluminum (2 × 1.5 m) was used.

The Ground Plane

was placed on a wooden table inside an anechoic cham- ber. The edges of the ground plane were covered by mi- crowave absorbers to limit the effect of reflections from nearby objects (Dawson et al., 2001). The heatsink block (88 × 34 × 53 mm) was supported by a small dielectric block 88 × 34 × 5 mm (not included in the numerical model) over a ground plane. A MOSFET (TO-247) was placed on the heatsink. The electric isolator was inserted between the case of the power device and the heatsink. The thickness and di- electric constant of Mica are 0.05 mm and 3.5, respectively.

In order to create the excitation source the SMA- type con- nector was connected to the pin (drain) of the semiconductor. Published by Copernicus Publications on behalf of the URSI Landesausschuss in der Bundesrepublik Deutschland e.V.

240

J. Kulanayagam et al.: Numerical modeling for heatsink emissions in power electronics

Ground Plane

Fig. 2. Experimental setup (heatsink frontally and monopole an- tenna vertically). The access of the connector was connected to the network analyzer via coaxial cable. A 7.5 cm high monopole antenna (1 mm diameter), 1 m from the centre of the heatsink block, sensed the radiated emissions from the heatsink for model validation purposes. The network analyzer was used to de- termine the transmission parameters from the heatsink to the monopole antenna (S21) in order to validate the model. The simplified model (without microwave absorbers around the table) shown in Fig. 2 is used for experimental purposes.

Numerical Modeling

In order to compute the electromagnetic field outside the heatsink model in the far field environment, CST Microwave Studio was used. In the numerical model all metallic parts are considered as Perfect Electric Conductor (PEC) materi- als. The heatsink block was placed over the infinite ground plane without the small dielectric support. It was assumed that the permittivity of the materials remained constant in the considered frequency range.

Results And Discussions

Non-grounded and grounded heatsink models are necessary to analyze the differing process conditions of a heatsink.

Non-Grounded Heatsink

The noise current is generated due to the parasitic capaci- tances of the heatsink design. This noise current can be cal- culated according to the following assumption. In the first approach for low frequencies, the capacitance between the case of the power device and the heatsink Cdh is much greater than the capacitance between the heatsink and ground plane

Unoise

Fig. 3. Noise currents in the non-grounded heatsink. Chg. The common-mode current is not taken into account in this case. Firstly, the simplified non-grounded heatsink model (see Fig. 3) is considered.

Dt

.

(1)

For low frequencies Cdh >> Chg, the noise voltage can be

Calculated As Follows

unoise ≃uds .

(2)

The differential-mode current is given by following equation

Dt

.

Four Configurations Were Made For The Non-Grounded

heatsink block model. Firstly, the heatsink block was sup- ported by a small dielectric block with the relative permit- tivity εr = 1 over a ground plane. A MOSFET was placed on the heatsink. The electric isolator (Mica) was inserted between the case of the MOSFET and the heatsink. Fig. 4 shows the S21 parameter for the first configuration of the measured and simulated coupling (S21) for the frontally and laterally polarized heatsink. In order to compare the radi- ated emissions of the heatsink, the measured result of the frontally polarized heatsink was used as the reference curve for the non-grounded and grounded heatsink.

In order to change the parasitic capacitance between the heatsink and the power device, the thickness of the Mica was doubled in the second configuration. The results of the sec- ond configuration are shown in Fig. 5. As expected, the re- sults of the first and second configuration are the same. The

Deployment In Out-Of-Position Situations
