Abstract — Multiphase Buck Converter MATLAB
stacks, simulation worlds, reports and viva from Bangalore. Nonlinear systems, such as switching DC-DC boost or buck converters, have rich dynamics. A simple one-dimensional discrete-time model is used to analyze the boost or buck converter in discontinuous conduction mode. Seven diIerent control schemes (open-loop power stage, voltage mode control, current mode control, constant power load, constant current load, constant- on-time control, and boundary conduction mode) are analyzed systematically. The linearized dynamics is obtained simply by taking partial derivatives with respect to dynamic variables. In the discrete-time model, there is only a single pole and no zero. The single closed-loop pole is a linear combination of three terms: the open-loop pole, a term due to the control scheme, and a term due to the non-resistive load. Even with a single pole, the phase response of the discrete-time model can go beyond -90 degrees as in the two-pole average models. In the boost converter with a resistive load under current mode control, adding the compensating ramp has no eIect on the pole location. Increasing the ramp slope decreases the DC gain of control-to- output transfer function and increases the audio-susceptibility. Similar analysis is applied to the buck converter with a non-resistive load or variable switching frequency. The derived dynamics agrees closely with the exact switching model and the past research results.
Analytical & State-Space Control Methodology
KEY WORDS: Nonlinear system, DC-DC power conversion, discrete-time model, non-resistive load, discontinuous conduction mode, small-signal analysis Figure 1: Power Converter Circuit Schematic & Electrical Interfacing for Multiphase Buck Converter Matlab Scheme Four (S4): Boost Converter with a Resistive Load in Parallel with CPL . .
Simulink Waveforms & Power Quality Findings
Scheme Five (S5): Boost Converter with a Resistive Load in Parallel with CCL . . Part I. Resistive Load (Fixed Switching Frequency) (summarized in Table 2) Figure 2: Power Converter Circuit Schematic & Electrical Interfacing for Multiphase Buck Converter Matlab Part II. Non-Resistive Load (Fixed Switching Frequency) (summarized in Table 3) Power stage/VMC/CMC with constant current load (CCL) Part III. Part III. Variable Switching Frequency Control (summarized in Table 4) Nonlinear systems, such as switching DC-DC boost or buck converters, have rich dynamics. Many eIorts have been made in the past three decades to analyze the boost converter power stage in discontinuous conduction mode (DCM) based on average models . Fewer eIorts have been made to model the boost converter under current mode control (CMC) in DCM.
