Resonant Inverter Matlab Simulink: Power Electronics, MATLAB/Simulink & Circuit Modeling Integrated Analysis: MATLAB/Simulink · MOSFET/IGBT Gate Drivers · SPWM/SVPWM · THD Spectrum · ~4645 Words Chapter 1: Power Electronics Overview, System Specifications & Topology Modeling This article presents the basic theory of operation of proportional resonant controllers, and introduces a possible implementation for the control of single-phase voltage source inverters. The corresponding software is given for Simulink and C++ code and is made available for download.
Analytical & State-Space Control Methodology
Proportional resonant controllers (abbreviated PR controllers) are a particular type of transfer function that are often implemented for the closed-loop control of systems with a sinusoidal behavior. As their name indicates, they possess both a proportional and a resonant term, which can be tuned independently. When needed, additional resonant terms can also be added to attenuate specific harmonics.
Simulink Waveforms & Power Quality Findings
In power electronics, proportional resonant controllers (PR) have attracted significant interest for AC current/voltage control applications due to their performance and simple implementation. In DC applications, conventional PI controllers provide excellent performance, notably a minimal steady-state error, thanks to the (almost) infinite DC gain provided by the integral control action. However, in AC applications, PI controller(s) in the stationary reference frame inevitably present a delayed tracking response, because finite gains at the fundamental frequency cannot prevent steady-state error.
