Thermal Management Power Converter: Power Electronics, MATLAB/Simulink & Circuit Modeling Integrated Analysis: MATLAB/Simulink · MOSFET/IGBT Gate Drivers · SPWM/SVPWM · THD Spectrum · ~6466 Words Chapter 1: Power Electronics Overview, System Specifications & Topology Modeling Digital control has become increasingly widespread in modern power electronic converters. When acquiring feedback signals such as the inductor current, synchronizing the analog-to-digital converter (ADC) with the digital pulse-width modulator (DPWM) is commonly employed to accurately track their steady-state average. However, the small-signal implications of such synchronization have not been investigated. This paper presents an exact small-signal model for digitally controlled buck converters operating in forced continuous-conduction mode (FCCM) under constant-frequency current-mode control, explicitly accounting for DPWM-ADC synchronization. Using a sampled-data framework, the proposed model captures all sideband effects introduced by the sampling process, yielding precise predictions of both analog and digital loop gains, even at frequencies beyond the switching and sampling frequencies. Both asymmetrical and symmetrical carrier modulations are considered. Furthermore, the digital loop gain is derived in closed form using the modified z-transform, enabling low-complexity compensator design and stability assessment. Within this framework, the analog loop gain can be directly obtained from the digital loop gain, thereby eliminating the need for computationally intensive infinite series evaluations. The validity of the proposed model is confirmed through both simulation and experimental results.

Analytical & State-Space Control Methodology

As digital control becomes increasingly popular in power converters, its advantages in cost, programmability, and integration over analog designs have made it the preferred choice. In particular, it greatly simplifies the realization of sophisticated without hardware modifications.

Simulink Waveforms & Power Quality Findings

In common engineering practice, digital power converter design typically begins with power stage modeling using the classical state-space averaging (SSA) technique [ 2 , 3 ] . An analog compensator is then designed in the continuous-time domain, discretized, and finally implemented in the digital controller. By averaging the piecewise linear state-spaces over one switching period, SSA eliminates the non-linearities. However, SSA neglects essential effects, such as computational delays, sampling, the presence of ripples, and sideband component coupling. Consequently, SSA loses validity even if the perturbation frequency is far below the switching frequency. While SSA leverages well-established linear time-invariant (LTI) control theory for rapid design, it fails to provide an accurate prediction of the closed-loop stability, particularly when the crossover frequency approaches the sampling frequency, leading to a potential risk of instability.
