Abstract — Dstatcom With Solar Pv Integration Project
this licence, visit http://creativecommons.org/licenses/by-nc-nd/4.0/ . Figure 1: Conceptual Model & Experimental Workflow for Dstatcom With Solar Pv Integration Project 2. System Architecture & Functional Block Diagram This paper presents a real-time simulation of a photovoltaic-based distribution static compensator (PV-DSTATCOM) using the Typhoon HIL 604 simulator, demonstrating its effectiveness in reactive power compensation, harmonic mitigation, and active power injection. The system seamlessly transitions between pure DSTATCOM mode, operating during night-time or when PV generation is zero, and PV-DSTATCOM mode, where it injects PV power while enhancing the power quality. A voltage source converter (VSC) regulated by an indirect current control strategy ensures improved power quality at the point of common coupling (PCC). Real-time simulation results under both balanced and unbalanced PCC voltage conditions validate the ability of the PV-DSTATCOM to mitigate power quality disturbances. Notably, the PV-DSTATCOM effectively reduces total harmonic distortion (THD), maintaining levels between 3.03%–5.58% under balanced PCC voltage and 3.95%–5.93% under unbalanced PCC voltage conditions, levels and non-linear load conditions. Additionally, it maintains a near-unity power factor operation at PCC and stabilizes the DC-link voltage at 900 V (± 5%), ensuring reliable operation.
Operational Methodology & Framework
Keywords: Harmonic mitigation, Indirect current control strategy, Maximum power point tracking, PV-DSTATCOM, Power quality, Reactive power compensation, Real-time simulation, Total harmonic distortion (THD) The rising integration of photovoltaic (PV) systems into power distribution networks presents significant challenges in combined with non-linear and unbalanced loads, causes harmonic distortions, reactive power imbalances, and voltage fluctuations at the point of common coupling (PCC) 1 – 4 . These issues contribute to increased power losses, equipment malfunctions, and potential non-compliance with regulatory standards 5 , 6 . In three-phase four-wire power distribution networks, unbalanced loading and harmonic currents further intensify these challenges, causing excessive heating of neutral conductor 7 – 11 . Effective mitigation strategies are a requisite to ensure reliable grid operation. A PV-based distribution static compensator (PV-DSTATCOM) presents a promising solution by facilitating seamless PV integration while enhancing power quality 12 . However, real-time performance of PV-DSTATCOM under practical grid conditions requires thorough evaluation. Factors such as balanced and unbalanced PCC voltages, fluctuating solar irradiance level, and sudden non-linear load variations can significantly impact its effectiveness 13 .
