Pyranometer Interfacing With Esp32 Project Comprehensive Technical Investigation & Design Architecture · Prepared for Research & Evaluation 1. Executive Overview & Research Problem Statement Overview:- A solar radiation monitoring system developed using ESP32, a mini solar panel, and an OLED display. The system measures global solar irradiance, including both direct and diffuse solar radiation, and displays real-time readings.
Operational Methodology & Framework
Components:- ESP32 WROOM Mini Epoxy Solar Panel OLED Display (SSD1306) PCB Board Features Real-time solar radiation monitoring OLED-based data visualization Compact PCB implementation Low-power operation Applications Solar energy assessment Renewable energy studies Environmental monitoring Reading solar irradiance from a Kipp & Zonen CMP-series pyranometer using an ESP32 and a 16-bit ADS1115 ADC.
Experimental Findings & Validation
Covers the CMP6, CMP10, CMP11, CMP21 and CMP22 pyranometers, and the CMA6 and CMA11 albedometers. A pyranometer measures global horizontal irradiance : the total shortwave solar power falling on a horizontal surface, in watts per square metre.
Scope & Practical Applications
